Quick Details
-
Name:
-
solder seal wire connectors
-
Color:
-
White Red Blue Yellow
-
Certificate:
-
IMDS, ISO, SGS
-
Application:
-
Wire Connecting
-
Tensile Strength:
-
Exceeds strength of conductor
-
Material:
-
PE
-
Dielectric Strength:
-
≥25kV/mm
-
Voltage Resistant:
-
>600V
-
Protection type:
-
IP67
-
Operating temperature:
-
-55°C~125°C
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Hampool
-
Model Number:
-
HP-SST-100
-
Name:
-
solder seal wire connectors
-
Color:
-
White Red Blue Yellow
-
Certificate:
-
IMDS, ISO, SGS
-
Application:
-
Wire Connecting
-
Tensile Strength:
-
Exceeds strength of conductor
-
Material:
-
PE
-
Dielectric Strength:
-
≥25kV/mm
-
Voltage Resistant:
-
>600V
-
Protection type:
-
IP67
-
Operating temperature:
-
-55°C~125°C
| Product Code | Photo |
L (mm) |
Qty Item 2 |
A Min (mm) |
Wire Dimensions(mm) | Cable Size | ||
| B Min |
B Max
C Max |
C Min | ||||||
| HP-SST-105-01 |
|
26 | 1 | 1.7 | 0.4 | 1.7 | 0.76 |
0.25-0.5mm² (26-24AWG) |
| HP-SST-105-02 |
|
40 | 1 | 2.7 | 1.3 | 2.7 | 1.2 |
0.5-1.5mm² (22-18AWG) |
| HP-SST-105-03 |
|
40 | 1 | 4.5 | 1.8 | 4.5 | 2 |
1.5-2.5mm² (16-14AWG) |
| HP-SST-105-04 | 40 | 1 | 6 | 2.8 | 6 | 3.4 |
4-6mm² (12-10AWG) |
|
Hampool Enterprise is a professional company to supply wire and cable systematic project solutions. We cooperated with German company, America company on technology and products. We have more than 10 years experience in this industry. With strong technology strength, Hampool develop many series high quality products and get good reputation in European market and North American market. After so many years development, Hampool has been a well known brand in many countries, and meanwhile Hampool become the pioneer brand to shift from "Made in China" to "Created in China".
