- Product Details
- {{item.text}}
Quick Details
-
Model name:
-
Van version
-
Seats:
-
2
-
Length(L103,mm):
-
5145
-
Width (W103,mm):
-
1720
-
height(H101,mm):
-
2000
-
Wheelbase(L101,mm):
-
3000
-
Curb weight(kg):
-
1610
-
Front track (W101,mm):
-
1445
-
rear track(W102,mm):
-
1420
Quick Details
-
Brand Name:
-
Dongfeng
-
Place of Origin:
-
Guangxi, China
-
Project code:
-
CM5EV 60KW
-
Model name:
-
Van version
-
Seats:
-
2
-
Length(L103,mm):
-
5145
-
Width (W103,mm):
-
1720
-
height(H101,mm):
-
2000
-
Wheelbase(L101,mm):
-
3000
-
Curb weight(kg):
-
1610
-
Front track (W101,mm):
-
1445
-
rear track(W102,mm):
-
1420
Product Description
| Project code | CM5EV 60KW | |
| Model name | Van version | |
| Model settings | Basic type | |
| Basic parameters | Length(L103,mm): | 5145 |
| Width (W103,mm): | 1720 | |
| height(H101,mm): | 2000 | |
| Wheelbase(L101,mm): | 3000 | |
| Front track/rear track(W101/W102,mm): | 1445/1420 | |
| The minimum ground clearance of the vehicle (no load/full load)(mm): | ≥170/160 | |
| Curb weight(kg): | 1610 | |
| Rated contained mass(kg): | 1160 | |
| Full load mass(kg): | 2900 | |
| Number of passengers: | 2 | |
| Front axle/rear axle (full load)(kg): | 1100/1800 | |
| 0~80km/h acceleration time (half load)(s): | ||
| Maximum speed(km/h): | 90 | |
| 30min continuous maximum speed(km/h): | 90 | |
| Maximum Gradeability (at Peak Torque)(%): | ≥20 | |
| Power consumption per 100 kilometers under CLTC conditions(kWh/100km): | ≤16 (actually subject to the announcement report) | |
| 60km/h constant speed cruising range(km): | N/A | |
| Cruising range under WLCT conditions(km): | ≥260 | |
| Electric motor | Motor type: | Permanent Magnet Synchronous Motor |
| Cooling type: | Water cooling | |
| Motor Warranty: | 5 years or 200,000 kilometers | |
| Peak power(kW/rpm): | 60 | |
| Rated power(kW/rpm): | 32 | |
| Motor maximum speed(rpm): | 9000 | |
| Peak torque(N.m/rpm): | 220 | |
| Power type: | Pure electric | |
| Main reduction ratio: | - | |
| Energy recovery system: | √ | |
| Battery | Power battery material: | Lithium iron phosphate battery |
| Cooling type: | Natural cooling | |
| Battery Warranty: | 5 years or 200,000 kilometers | |
| Battery heater: | √ | |
| Battery rated voltage(V): | 334.88 | |
| Battery capacity(kwh): | 41.86 | |
| Charge | Car charger power: | × |
| Slow charging interface (AC): | × | |
| Fast charging interface (DC): | √(inside the front warehouse) | |
| Charging port light: | × | |
| Charging port with lock: | × | |
| National standard 220V AC on-board charger (three to seven): | × | |
| 220V power output (bidirectional OBC): | × | |
| 7KW wall-mounted charging box: | × | |
| Charging status indicator light: | √(on the instrument cluster) | |
| Reservation charging function: | × | |
| Slow charging and charging time (meter power from 5% to 100%)(h): | × | |
| Fast charging time (SOC: 10%-80%, normal temperature 25°C): | 1h | |
