Quick Details
-
Brand Name:
-
BEFANBY
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Manufacture direct large table transfer cart on rails
-
Load capacity:
-
0-300T
-
Material:
-
Q235 steel
-
turning:
-
can be customized
-
OEM:
-
Accepted
-
Certification:
-
CE,ISO9001,SGS
-
Application:
-
Warehouse ,factory and material handling
-
Power supply:
-
battery power
Quick Details
-
Warranty:
-
2 years
-
Weight (KG):
-
1000
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
BEFANBY
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Manufacture direct large table transfer cart on rails
-
Load capacity:
-
0-300T
-
Material:
-
Q235 steel
-
turning:
-
can be customized
-
OEM:
-
Accepted
-
Certification:
-
CE,ISO9001,SGS
-
Application:
-
Warehouse ,factory and material handling
-
Power supply:
-
battery power
Products Description
Steerable turning motorized material handling on rail transfer cart
BEFANBY designed and manufactured the battery powered transfer car and provide innovative handling solution with more than 20 years' experience.The transfer car can be used in industry plant, port, workshop, production line and so on to transport ladle,coil, mold, steel products, workpiece and so on.All the solution are designed as per customers true demand.
The battery powered transfer cart is a good choice if meeting the following features:
1.The running distance is not limited for the battery powered transfer car
2.Low using frequency(The spare battery can be provided if higher using frequency)
3.Despite of turning or going straight, the transfer car can realize
4.Despite of running on indoor or outdoor, high temperarture or explosive environment, ferry or cross rail, the transfer cart can realize.
5.Dimensions,capacity, loading platform superstructure, speed and many others special funcition can be customized as per client request
2.Low using frequency(The spare battery can be provided if higher using frequency)
3.Despite of turning or going straight, the transfer car can realize
4.Despite of running on indoor or outdoor, high temperarture or explosive environment, ferry or cross rail, the transfer cart can realize.
5.Dimensions,capacity, loading platform superstructure, speed and many others special funcition can be customized as per client request
Details Images
Product Parameter
|
Modle
|
KPX-10T
|
KPX-30T
|
KPX-50T
|
KPX-80T
|
KPX-100T
|
KPX-150T
|
|||||
|
Table Size (m)
|
3.6*2.0*0.5
|
4.5*2.2*0.6
|
5.5*2.5*0.65
|
6.0*2.6*0.8
|
6.5*2.8*0.9
|
10*3.0*1.2
|
|||||
|
Power
|
Maintenance Free Battery
|
|
|
|
|
|
|||||
|
Rail inner Gauge
|
1435mm
|
1435mm
|
1435mm
|
1800mm
|
2000mm
|
2000mm
|
|||||
|
Wheel Dia.
|
350mm
|
400mm
|
500mm
|
600mm
|
600mm
|
600mm
|
|||||
|
Running Speed
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
0-20m/min
|
|||||
|
Motor Power
|
1.6kw
|
3.5kw
|
5kw
|
8kw
|
10kw
|
15kw
|
|||||
|
Battery Capacity
|
180Ah
|
250Ah
|
330Ah
|
400Ah
|
440Ah
|
600Ah
|
|||||
|
Battery Volatge
|
48v
|
48v
|
48v
|
72v
|
72v
|
72v
|
|||||
|
Max Wheel Load
|
42.6Kn
|
110.4Kn
|
174Kn
|
278.4Kn
|
343.8Kn
|
265.2Kn
|
|||||
|
Reference weight
|
4.2t
|
6.8t
|
8t
|
12.8t
|
14.6t
|
26.8t
|
|||||
|
Recommend Rail
|
P24
|
P38
|
P43
|
P50
|
QU100
|
QU100
|
|||||
Remark:
the technical parameter of the transfer car only can be make reference above.All can be customized manufacturing as per your true demand. please contact us if any doubt. Our professinal engineer will help you solve the transfer problems in any time.
Function
Product Features
Shipping
Our Company
Related Products
FAQ
Q
What is the size and load of the motorized transfer cart?
A
The size and load of our the motorized transfer cart are customized design according to your requirement.
Q
How should I operate the motorized transfer cart?
A
The motorized transfer cart is controlled by pendant & remote radio control. The controller could be a push button or joy-sticker.
Q
Whether there is professional technician assist our installation?
A
Yep, we have professional installation teams, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So we can arrange technicians.
Q
Can you help us arrange the shipment?
A
Yep, we have professional and independent Logistics & Document department. They will be responsible for arrange the logistics. Just communicate with our sales about the destination port.
