Quick Details
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Self loading and unloading container semi-trailer
-
Suspension:
-
Mechanical Suspension
-
Function:
-
Transport Heavy Duty Equipment
-
Axle:
-
Fuhua brand
-
Tire:
-
11.00r20 12r22.5 315 385
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Brake System:
-
WABCO
-
Loading capacity:
-
60-100tons
-
Condition:
-
Brand-new
-
Tank material:
-
Carbon Steel
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
60t
-
Brand Name:
-
sinotruk
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Self loading and unloading container semi-trailer
-
Suspension:
-
Mechanical Suspension
-
Function:
-
Transport Heavy Duty Equipment
-
Axle:
-
Fuhua brand
-
Tire:
-
11.00r20 12r22.5 315 385
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Brake System:
-
WABCO
-
Loading capacity:
-
60-100tons
-
Condition:
-
Brand-new
-
Tank material:
-
Carbon Steel
Sinotruk
Self loading and unloading container semi-trailer
Our Main Products Heavy Trucks and Construction Machinery. include Howo tractor trucks, dump trucks, trailer truck,Fire trucks, water tank trucks, concrete mixer trucks, special trucks,truck parts and Motor grader,wheel loader, roller loader. we can supply these for our clients with good quality and competitive price.
Product Description
Specification
|
SELF LOADING AND UNLOADING CONTAINER SEMI-TRAILER SPECIFICATIONS
|
|
|
||
|
This model is mainly used for short distance transportation of containers, and its main function is to load and unload standard containers by itself; Applicable to container specifications 40# and 45# and other containers; Solve the cost and timeliness of terminal services;
The model is mainly composed of container skeleton semi-trailer chassis, container crane assembly, container gripper assembly, container rear roll stabilizer, rear stable hydraulic support roller, hydraulic distribution system, electrical control system, etc. |
|
|
||
|
Brand
|
|
SINOCTM
|
||
|
Dimension (LxWxH) (unloaded)
|
|
133755×2550×3750(mm)
|
||
|
Overhang (rear)
|
|
2360(mm)
|
||
|
Wheel base
|
|
6250+1310+1310(mm)
|
||
|
Curb weight
|
|
9000(kg)
|
||
|
Gross vehicle weight
|
|
40000(kg)
|
||
|
Container crane Specifications
|
|
|
||
|
Max. Lifting Capacities
|
|
40000(kg)
|
||
|
Hydraulic Oil Tank
|
|
90L
|
||
|
Hydraulic Piston Pump
|
|
60L / min
|
||
|
Working Pressure
|
|
20Mpa
|
||
|
Self loading and unloading time
|
|
About 3 minutes/per working cycle
|
||
|
control method
|
|
Wireless rocker control
|
||
|
Packing
|
Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
|
|
||
