Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Electrical Life:
-
100,000 times above
-
Certificate:
-
TUV CCC CE RoHS
-
Material Body:
-
Aluminium
-
OEM:
-
Acceptable
-
Mechanical Life:
-
1,000,000 times above
-
Contact Form:
-
1C
-
Outgoing Cabel:
-
Feasible
-
Colour:
-
Free Choice
-
Inner Switch:
-
XZ-15GW22-B
-
Operating temperature:
-
-20-70 degree
Quick Details
-
Protection Level:
-
IP65
-
Max. Current:
-
15A
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Electrical Life:
-
100,000 times above
-
Certificate:
-
TUV CCC CE RoHS
-
Material Body:
-
Aluminium
-
OEM:
-
Acceptable
-
Mechanical Life:
-
1,000,000 times above
-
Contact Form:
-
1C
-
Outgoing Cabel:
-
Feasible
-
Colour:
-
Free Choice
-
Inner Switch:
-
XZ-15GW22-B
-
Operating temperature:
-
-20-70 degree
- Kinds of shell's material for choice, such as engineering plastic, steel panel, aluminium alloy, etc.
- Metal shell use the stregenthening to reast the surface, bears the impact, the wearability, thermostable.
- Cable lock-in jacket is made for the cable coming out and it is waterproof, grease proofing.
- Switch bottom is equipped with the rubber pad, for skidproof.
- Widely used for control in industrial automation equipments, transport, pressing, medical treatment, test and etc.
| Contact Resistance | 25mΩ(initial value) |
| Insulation Resistance | 100 m Ω(above) DC500V |
| Withstand Voltage | ≥2000VAC |
| Mechanical Life | 1,000,000 Above |
| Electrical Life | 100,000 Above |
| Operating Temperature | -20~+70℃ |
| Operating Humidity | ≤85% |
- According to the difference of load and current value, rated load should be taken note. Current value series is 10A, 15A and 16A.
- When transporting and moving, pls take note of the short circuit or open circuit may happen in internal wiring.
- Please take note of the level of protection when used in water, oil and bug dust. This series has protective type and unprotective type.
- The immediate cause for broken is stress and attack, please pay attention.
- Warning mark 'Danger! High Voltage!' and 'Take note!' remind us pay attention to personal safety and correctly operation.
| Material | Aluminium |
| Inner Switch | XZ-15GW22-B |
| Rating Load | 15A/250VAC |
| Contact Form | 1C |
| Outgoing Cable | -- |
| Protection Degree | IP65 |
- Quality Assurance: We offer replacement if you receive defective or wrong items in 12 months from the shipping date.
- Supplied directly from factory with more than 16 years experience.
- Short Delivery Time: Stock in 2 days, order as short as 7 days.
- Small order welcome.
- Payment by Paypal, Western Union is supported.
Zhejiang Xurui Electronic Co., Ltd, established in 2002 , is specialized in the research, development, production of industrial products.
Xurui has a modern workshop covering more than 2,000 square meters. There are about 120 employees, incuding more than 10 years experienced technicians.
Main Products: 1. Micro Switch; 2. Limit Switch; 3. Toggle Switch; 4. Foot Switch; 5. Solid State Relay; 6. Reed Switch; 7. Proximity Switch.
Main markets: Europe, America, Australia, Asia, Middle East and so on.
Q: How do you control the products' quality?
A: 100% auto inspection machine and manual test together before packing.
Q: Would you accept to use our logo?
A: If you have good quantity, we would like to do OEM and ODM, customized specification.
Q: Can I get a sample for reference?
A: We are glad to send the samples for testing. Samples are free, but you may need to pay the express cost.
Q: What's your delivery time?
A: Normally it takes 15-20 working days for production. If we get stock, it only takes two days.
