Quick Details
-
Panel Size:
-
128*128 mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P2
-
Scan:
-
1/32 S
-
Brightness:
-
1000- 3000 cd/sqm
-
IP grade:
-
IP 43
-
Life span:
-
96,360 hours
-
Use Voltage:
-
AC 220V/110V±10%
-
Certificate:
-
CE RoHS FCC Certifications
-
LED chip:
-
Cree + Nichia + Epistar + Opto + Silan
-
Warranty:
-
2~5 Years
-
Refresh Rate:
-
1920 -3840 Hz
-
Package:
-
Wooden Case
Quick Details
-
Application:
-
Indoor, Advertising/Stage background
-
Brand Name:
-
HONGHUI
-
Color:
-
full color
-
Panel Size:
-
128*128 mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P2
-
Scan:
-
1/32 S
-
Brightness:
-
1000- 3000 cd/sqm
-
IP grade:
-
IP 43
-
Life span:
-
96,360 hours
-
Use Voltage:
-
AC 220V/110V±10%
-
Certificate:
-
CE RoHS FCC Certifications
-
LED chip:
-
Cree + Nichia + Epistar + Opto + Silan
-
Warranty:
-
2~5 Years
-
Refresh Rate:
-
1920 -3840 Hz
-
Package:
-
Wooden Case
Specification
|
P2 Indoor Fixed
|
|
|
|
Best viewing distance
|
2-15 m
|
|
|
Viewing angle
|
140° W ; 140 °H
|
|
|
Input power frequency
|
60 Hz
|
|
|
Defect rate
|
≤0.0001
|
|
|
Maintenance mode
|
front / back
|
|
|
Average power consumption
|
300 W / m2
|
|
|
Max power consumption
|
600 W / m2
|
|
|
Operating temperature
|
–30℃ ~ +60 ℃
10% ~ 95% RH
|
|
Product Description
|
|
P2 Indoor
LED module
|
|
Pixel pitch
|
2 mm
|
|
Pixel configuration
|
SMD 2121
|
|
IC
|
MBI 5124 / MBI 5153
|
|
LED lamp
|
Nation Star / Epistar / Kinglight
|
|
|
P2 Indoor
LED module
|
|
Module size
|
128*128 mm / 256*128 mm
|
|
Module resolution
|
64*64 pixel / 128*64 pixel
|
|
Pixel density
|
250,000 dots/m2
|
|
Scan
|
1/32 S
|
|
|
P2 Indoor
LED cabinet
|
|
Cabinet size
|
512*512 mm
|
|
Cabinet resolution
|
256*256 pixel
|
|
Cabinet material
|
Iron
|
|
Cabinet weigt
|
35 kg/m2
|
|
Controller card
|
Nova Star /Linsn /Colorlight
|
|
Control method
|
Synchronization /Asynchronization
|
