Short press H and V button on the keypad to switch the Horizontal and Vertical laser lines separately.
The laser lines can be selected separately according to job requirements
- Product Details
- {{item.text}}
Quick Details
-
Wavelength:
-
OSRAM 505-520nm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
huepar
-
Model Number:
-
S04CG
-
Laser:
-
Germany Osram
-
Laser Color:
-
green
-
IP rating:
-
54
-
Mount size:
-
1/4'';5/8'
-
Type:
-
4 x 360° Green beam
-
Laser class::
-
Class 2 (IEC/EN60825-1/2014), <1mW power output
-
Screen type::
-
LCD screen with backlight
-
Working distance:
-
: 20m(60-100LUX),≥40m with detector
-
Power source::
-
7.4V / 2600mAh Li-ion battery & 4 x AA battery
-
Working hour::
-
7 hours
Quick Details
-
Warranty:
-
2 years
-
Size:
-
20 *25 *14.5
-
Precision:
-
±3mm/10m ±1/9 In. at 33 Ft.
-
Wavelength:
-
OSRAM 505-520nm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
huepar
-
Model Number:
-
S04CG
-
Laser:
-
Germany Osram
-
Laser Color:
-
green
-
IP rating:
-
54
-
Mount size:
-
1/4'';5/8'
-
Type:
-
4 x 360° Green beam
-
Laser class::
-
Class 2 (IEC/EN60825-1/2014), <1mW power output
-
Screen type::
-
LCD screen with backlight
-
Working distance:
-
: 20m(60-100LUX),≥40m with detector
-
Power source::
-
7.4V / 2600mAh Li-ion battery & 4 x AA battery
-
Working hour::
-
7 hours
Product Description
Product Description:
S04CG 4 x 360 Green Laser Level Specifications: * Laser Class: Class 2 (IEC/EN60825-1/2014), <1mW power output * Laser Wavelength: 520nm * Screen type: LCD screen with backlight * Horizontal/Vertical Accuracy: +/- 1/9 inch at 33Ft * Leveling/Compensation Range: +/-4° * Working Distance (Line): 20M(60-100 LUX), 40M with Huepar Receiver LR-5RG/LR-6RG * Operating Time: 6 hours continual use with all laser beams on * Power Source: 2600mAh Li-ion battery&Dry battery * IP Rating: IP54 dust-proof, waterproof and shockproof, reliable and tough * Operation Temperature Range: 14℉ ~ 122℉ (-10℃~ 50℃) * Storage Temperature Range: -4℉ ~ 158℉ (-20℃~ 70℃) * Mount Size: 1/4"-20
WARNING:
● Do not point the laser beam directly into the eyes.
S04CG 4 x 360 Green Laser Level Specifications: * Laser Class: Class 2 (IEC/EN60825-1/2014), <1mW power output * Laser Wavelength: 520nm * Screen type: LCD screen with backlight * Horizontal/Vertical Accuracy: +/- 1/9 inch at 33Ft * Leveling/Compensation Range: +/-4° * Working Distance (Line): 20M(60-100 LUX), 40M with Huepar Receiver LR-5RG/LR-6RG * Operating Time: 6 hours continual use with all laser beams on * Power Source: 2600mAh Li-ion battery&Dry battery * IP Rating: IP54 dust-proof, waterproof and shockproof, reliable and tough * Operation Temperature Range: 14℉ ~ 122℉ (-10℃~ 50℃) * Storage Temperature Range: -4℉ ~ 158℉ (-20℃~ 70℃) * Mount Size: 1/4"-20
WARNING:
● Do not point the laser beam directly into the eyes.
Line Switching:
Line Switching
1.By app
* Short press "LASER" button to switch the laser lines.
* The laser lines can be selected separately according to job requirements.
* The laser line(s) can be temporarily turned OFF by phone when you need to leave for a while.
2.By remote control: press button "H" or "V" to switching line
With Remote control
The remote control enables to select three 360° laser lines individually at a distance up to 33Ft.
The laser line(s) can be temporarily turned OFF by the remote control when you need to leave for a while.
The laser line(s) can be temporarily turned OFF by the remote control when you need to leave for a while.
Self-leveling mode & Manual mode
Self-leveling mode:
When the laser tool is switched to the unlocked position, self-leveling mode is enabled. The laser beam will blink continuously at 2Hz when the tool is beyond self-leveling range (4°±1°).
Manual mode:
When the pendulum lock is in locked position, manual mode locks laser lines in place for use at any angle to project non-level straight lines. The laser beam will blink every 3-5 seconds to remind you that it's not self-leveling now
Pulse Mode
Pulse Mode
Turn ON pulse mode: Slide the pendulum to the Unlocked Position, then press and hold the power button to turn on the pulse mode,
the indicator lights up in red.
Application：When the pulse mode turned on, laser tool can be used with a laser receiver to work in brighter condition or a larger
working distance.
●When use with a receiver, it’s necessary to turn on the pulse mode
●It is compatible with
Huepar Line Laser Receiver
only.
Diverse Power Supply
Large-capacity li-ion battery: 6 hours of extra-long working & Can be charged with type-c port.
Bare battery charging: with type-c port.
Direct input charging: This laser tool can be used at job site with direct input charging even if take out the battery.
Charging protection help prevent the tool from overcharge.
Large-capacity li-ion battery: 6 hours of extra-long working & Can be charged with type-c port.
Bare battery charging: with type-c port.
Direct input charging: This laser tool can be used at job site with direct input charging even if take out the battery.
Charging protection help prevent the tool from overcharge.
Easy to Use
1. 360° Strong Magnetic Pivoting Base: Allows for attachment to metal track and steel，supporting you to turn the laser level
around at 360 degree , projecting lines at any angle.
2. Mount Size: 1/4"-20 mounting threads for temporarily fastening in place or being fixed on tripod.
around at 360 degree , projecting lines at any angle.
2. Mount Size: 1/4"-20 mounting threads for temporarily fastening in place or being fixed on tripod.
Outdoor Power-saving Pulse Mode:
When switch to pulse mode, the brightness of the laser line will be reduced to extend the working time and relieve eye strain.
Specification
|
Laser Color
|
green
|
|
Laser Standard
|
Class II
|
|
Laser Wavelength:
|
Osram 520nm
|
|
IP Rating
|
54
|
Product packaging
Packing Includes
* 1 xS04CG Laser Level
* 1 x Rechargeable Lithium Battery
* 1 x Lithium Battery Charger
* 1 x Power Adapter
* 4 x AA Batteries * 1 x AA Battery Holder
* 1 x Magnetic Pivoting Base
* 1 x Lifting Base
* 1 x Lase Level User Manual
* 1 x User Manual
* 1 x Bluetooth Remote Control
* 1 x Hard Carry Case
* 1 x Rechargeable Lithium Battery
* 1 x Lithium Battery Charger
* 1 x Power Adapter
* 4 x AA Batteries * 1 x AA Battery Holder
* 1 x Magnetic Pivoting Base
* 1 x Lifting Base
* 1 x Lase Level User Manual
* 1 x User Manual
* 1 x Bluetooth Remote Control
* 1 x Hard Carry Case
