Pri ting Unit: it uses advanced US ink supplying system to ensure the shinning of the print. China's first low-speed differential water supply system, effectively ensuring the high, low speed of the ink-water balance and color stability; water bridge ink roller by a version in the first ink roller to achieve the unity of the classic structure of the ink to reach the pre-equilibrium, significantly reduce paper waste; pioneered use of floating roller, effectively prevent s the ink bars and ghost . The ink line is made up of 18 ink rollers and 5dampening rollers ( Alcohol System). Both film and paper can be printed in this machine
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
380V
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
WANJIE
-
Dimensions(L*W*H):
-
11000*4000*1900mm
-
Weight:
-
1.6t
-
Paper Thickness:
-
60-350gsm
-
Printing speed:
-
180 rpm/min
-
Function:
-
BOX printing
-
Suitable printing material:
-
adhesive paper, paper, bopp, pvc, opp
-
Option:
-
flexo, rotary die cut , cold foil
-
Ink rollers:
-
19pcs (4 Form Rollers)
-
Certification:
-
CE ISO
Quick Details
-
Condition:
-
New
-
Plate Type:
-
offset printer
-
Color & Page:
-
Multicolor
-
Voltage:
-
380V
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
WANJIE
-
Dimensions(L*W*H):
-
11000*4000*1900mm
-
Weight:
-
1.6t
-
Paper Thickness:
-
60-350gsm
-
Printing speed:
-
180 rpm/min
-
Function:
-
BOX printing
-
Suitable printing material:
-
adhesive paper, paper, bopp, pvc, opp
-
Option:
-
flexo, rotary die cut , cold foil
-
Ink rollers:
-
19pcs (4 Form Rollers)
-
Certification:
-
CE ISO
---Fully servo motor system from YASKAWA
---Pre-register system
---Plate cocking(skewing)adjustment)
---Heavy offset printing unit
---Independent lubircation system for each unit
---Automatic and Manual plate mounting system
---Partition ink fountain
---Unwinder and rewinder adopts penumatic paper loading
Main Specification:
|
Items |
Specifications |
|
|
Max. printing Area |
540*410mm |
|
|
Diameter of unwinding web |
800mm |
|
|
Diameter of rewinding web |
800mm |
|
|
Thickness of printing material |
80 -3 5 0gsm |
|
|
Printing Length |
210 -420 mm |
|
|
Printing speed |
30- 150rpm/min |
|
|
Power |
39.5KWfor 6 color |
|
|
UV |
10KW/color |
|
|
Overall dimensions |
11 00 0 * 4000 *1 9 00mm（L*W*H） |
|
|
Machine weight |
16 000 kgs |
