Adopting gray level Ricoh stainless steel internal heating industry head which has high performance in speed and resolution. It is suitable for long time working, 24 hours running.
- Product Details
- {{item.text}}
Quick Details
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ntek
-
Voltage:
-
220v
-
Dimensions(L*W*H):
-
4.4*2.1*1.4m
-
Weight:
-
1500 KG
-
Marketing Type:
-
Hot Product 2023
-
Product name:
-
inkjet printer printing machine 2513
-
Print head:
-
Ricoh Gen5/Gen6 Printhead
-
Printing material:
-
Flatbed Material
-
After-sales Service Provided:
-
Provided
-
Ink:
-
UV Curing Ink
-
Color:
-
CMYK+W+V+LC+LM
-
Speed:
-
15-18 Sqm/h
-
Software:
-
Photo Pint
-
File Format:
-
TIFF,JPEG,Postscript,EPS,PDF etc.
Quick Details
-
Print Dimension:
-
2500mm*1300mm
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ntek
-
Voltage:
-
220v
-
Dimensions(L*W*H):
-
4.4*2.1*1.4m
-
Weight:
-
1500 KG
-
Marketing Type:
-
Hot Product 2023
-
Product name:
-
inkjet printer printing machine 2513
-
Print head:
-
Ricoh Gen5/Gen6 Printhead
-
Printing material:
-
Flatbed Material
-
After-sales Service Provided:
-
Provided
-
Ink:
-
UV Curing Ink
-
Color:
-
CMYK+W+V+LC+LM
-
Speed:
-
15-18 Sqm/h
-
Software:
-
Photo Pint
-
File Format:
-
TIFF,JPEG,Postscript,EPS,PDF etc.
Products Description
UV flatbed printer can widely print on glass, ceramic tile, PVC, aluminum sheet, wood ,MDF,board, metal panel, billboard, acrylic panel, paper board, foam board, corrugated cardboard, leather, flex banner, canvas, mesh paper, sticker, wall coverings, etc.
Printhead
RICOH GEN5/GEN6/
Printhead 2-8 units
Application
Wide range of applications
Print Effect
Color, white,varnish and 3D embossing effect optional
Product Paramenters
|
Product Model
|
YC2513L
|
|
|
|
|||
|
Printhead Type
|
RICOH GEN5/GEN6
|
|
|
|
|||
|
Printhead Number
|
2-8 heads
|
|
|
|
|||
|
Ink Characteristics
|
UV Curing Ink (VOC Free)
|
|
|
|
|||
|
Ink reservoirs
|
Refillable on the fly while printing/2500ml per color
|
|
|
|
|||
|
LED UV Lamp
|
more than 30000-hours life made in Korea
|
|
|
|
|||
|
Printhead arrangement
|
CMYK LC LM W V Optional
|
|
|
|
|||
|
Printhead Cleaning System
|
Automatic Cleaning System
|
|
|
|
|||
|
Guide Rail
|
TAIWAN HIWIN/THK Optional
|
|
|
|
|||
|
Working Table
|
Vacuum Sucking
|
|
|
|
|||
|
Printing Size
|
2500*1300mm
|
|
|
|
|||
|
Print Interface
|
USB2.0
|
|
|
|
|||
|
Media Thickness
|
0-100mm
|
|
|
|
|||
|
Print Resolution& Speed |
720X600dpi
|
4PASS
|
15-33sqm/h
|
|
|||
|
|
720X900dpi
|
6PASS
|
10-22sqm/h
|
|
|||
|
|
720X1200dpi
|
8PASS
|
8-18sqm/h
|
|
|||
|
Life of printed image
|
3 years(outdoor),10years(indoor)
|
|
|
|
|||
|
File Format
|
TIFF,JPEG,Postscript,EPS,PDF etc.
|
|
|
|
|||
|
RIP Software
|
Photoprint Ntek Edition
|
|
|
|
|||
|
Power Supply
|
220V 50/60Hz(10%)
|
|
|
|
|||
|
Power
|
3100W
|
|
|
|
|||
|
Operation Environment
|
Temperature 20 to 30 ℃,Humidity 40% to 60%
|
|
|
|
|||
|
Machine Dimension
|
4.4*2.1*1.4m
|
|
|
|
|||
|
Packing Dimension
|
4.6*2.26*1.71m
|
|
|
|
|||
|
Weight
|
1500kg
|
|
|
|
|||
|
Warranty
|
12 months exclude the consumables
|
|
|
|
|||
Machine Details
Ricoh Print Head
Integral Welded Industrial Steel Frame
The frame adopts the integral welding of 8cm*16cm square steel to ensure the stability of the frame structure without deformation.
The platform base struct-ure adopts high precision gantry milling machine.
Vacuum Adsorption Platform
Hard oxidized honeycomb hole section-alized adsorption platform, strong adso-
rption capacity, low motor consumption, customers can adjust the adsorption area according to the size of the printing
material,the platform surface hardness is high, scratch resistance, corrosion resistance.
German IGUS Energy Chain
Germany IGUS mute drag chain on X axis, ideal for protection of cable and tubes under high speed motion. With high performance,low
noise, make the working environment more comfortable.
Lead screw bar
Adopting dual-level precision screw rod ensure the both sides of Y axis synchonous running.
Other Details
Ricoh Piezoelectric Nozzle
Adopt Ricoh piezoelectric nozzle, one nozzle 384/1280 nozzles, the accuracy can reach 1440dpi, the new variable ink drop technology, provide 7/14/21pl ink dot size, can achieve high speed or low resol-ution cases can also easily achieve high quality picture, to achieve no point printing effect.
CMYK+W+V All three colors at once
The use of gloss oil makes the product more gorgeous gloss and "high gloss" effect, not only makes the surface of the whole picture has a gloss sense, get a more exquisite printing effect, but also can better protect the coating, make the product more durable.
Printing Samples
Photo case
3d printing
Acrylic
Bamboo fiber board
Advertising printing
Ceramic tile
Decoration
Mouse pad
PVC
Artware
Foam board
Metal Printing
Wood
Glass
Leather
