Quick Details
-
Engine Brand:
-
Shangchai SC7H180.2G3
-
Travel Speed:
-
0~15 km/h
-
Place of Origin:
-
China
-
Brand Name:
-
Liugong
-
Dimension(L*W*H):
-
4970*2800*3340MM
-
Drum diameter:
-
6770MM
-
Exciting Force:
-
110KN
-
Machine name:
-
Pneumatic Tire Roller
-
Machine model:
-
6530E
-
Condtion:
-
100% new
-
Working weight:
-
30000kg
-
MOQ:
-
1
-
Static Linear Load(Front):
-
240 N/cm
-
Vibration Frequency:
-
35 Hz
-
Minimum turning radius:
-
7500 mm
-
Dimension:
-
4900*1900*2660 mm
Quick Details
-
Type:
-
Tire Roller
-
Power:
-
132 (179 hp)
-
Weight:
-
30 Ton
-
Engine Brand:
-
Shangchai SC7H180.2G3
-
Travel Speed:
-
0~15 km/h
-
Place of Origin:
-
China
-
Brand Name:
-
Liugong
-
Dimension(L*W*H):
-
4970*2800*3340MM
-
Drum diameter:
-
6770MM
-
Exciting Force:
-
110KN
-
Machine name:
-
Pneumatic Tire Roller
-
Machine model:
-
6530E
-
Condtion:
-
100% new
-
Working weight:
-
30000kg
-
MOQ:
-
1
-
Static Linear Load(Front):
-
240 N/cm
-
Vibration Frequency:
-
35 Hz
-
Minimum turning radius:
-
7500 mm
-
Dimension:
-
4900*1900*2660 mm
|
Max. Operating Mass
|
30000 kg
|
|
Min. Operating Mass
|
15000 kg
|
|
Single Tire Load
|
15000 kg
|
|
Overlapping of Front & Rear Tire
|
45 mm
|
|
Model
|
Shangchai SC7H180.2G3
|
|
Emission Regulation
|
Stage III
|
|
Rated Power
|
132 (179 hp) @ 2200 rpm
|
|
Working Speed
|
0~7 km/h
|
|
Traveling Speed
|
0~15 km/h
|
|
Compacting Width
|
2750 mm
|
|
Theoretical Gradeability
|
20%
|
|
Min. Ground Clearance
|
360 mm
|
|
Wheelbase
|
3840 mm
|
|
Min. Outside Turning Radius
|
9000 mm
|
|
Tire Type
|
11.00-20-16PR
|
|
Tire Numbers
|
Front 5 Rear 6
|
|
Overall Length
|
4970 mm
|
|
Overall Width
|
2800 mm
|
|
Overall Height
|
3340 mm
|
Specifications :
* Top quality compaction is achieved by the kneading and rolling effect of the wheels as vertical pressure combined with
horizontal forces produce an excellent, uniform surface finish.
* On uneven surfaces, our patented Tire Suspension System, equipped with a tiltable front shaft, enables the 4 front wheels to
swing up and down by +/- 8° achieving maximum ground contact for each wheel. This delivers optimum compact and improves safety
by helping prevent the roller from tilting over.
* Safety is further enhanced with a three-stage breaking system utilizing hydraulics, oil cut-off and wheel side oil breaking.
This three stage system protects the operator, site workers and members of the public from accidents.
horizontal forces produce an excellent, uniform surface finish.
* On uneven surfaces, our patented Tire Suspension System, equipped with a tiltable front shaft, enables the 4 front wheels to
swing up and down by +/- 8° achieving maximum ground contact for each wheel. This delivers optimum compact and improves safety
by helping prevent the roller from tilting over.
* Safety is further enhanced with a three-stage breaking system utilizing hydraulics, oil cut-off and wheel side oil breaking.
This three stage system protects the operator, site workers and members of the public from accidents.
