1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve

1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve

FOB Reference Price: Get Latest Price
≥50 Sets
US $11
≥100 Sets
US $9
≥500 Sets
US $8
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Model Number:
HKWS10 Solenoid Valve
Brand Name:
COVNA
Number of Ways:
2 Way Solenoid Valve
Valve Operation Type:
Normally Closed Solenoid Valve
Sealing Material:
NBR
Pressure:
Low Pressure Solenoid Valve
Coil Voltage:
12V DC Solenoid Valve
Material:
Plastic Solenoid Valve
End Connection:
NPT Threaded Solenoid Valve
Certification:
ROHS, CE, ISO9001

Quick Details

Port Size:
1/8"~1/4", DN06~DN06
Warranty:
1 YEAR
Place of Origin:
Guangdong, China
Model Number:
HKWS10 Solenoid Valve
Brand Name:
COVNA
Number of Ways:
2 Way Solenoid Valve
Valve Operation Type:
Normally Closed Solenoid Valve
Sealing Material:
NBR
Pressure:
Low Pressure Solenoid Valve
Coil Voltage:
12V DC Solenoid Valve
Material:
Plastic Solenoid Valve
End Connection:
NPT Threaded Solenoid Valve
Certification:
ROHS, CE, ISO9001
Specifications
Item
1/4 inch 2 Way 12VDC Normally Closed PP Plastic Washing Machine Mini Solenoid Valve Water Inlet Valve
Size Range
1/8" ~ 1/4", DN06~DN08
Medium
Water, Air, Steam, Gas, Oil, etc
Structure
Direct Acting
Temperature
NBR: -5℃~80℃; EPDM: -5℃~120℃; VITON: -5℃~120℃
Pressure
0~0.7MPa
Port Thread
NPT, BSPP, BSP
Voltage
DC-12V, 24V
AC-24V, 120V, 240V/60Hz; 110V, 220v/50Hz
Tolerance
±10%
Material
Body: PP, POM
Seal: VITON, NBR, EPDM
Plunger: Stainless Steel 430F
Stop: SS403F
Springs: SS304
Application
Food & Beverage, Water & Wastewater, Ultra Pure Water, Desalination, Chemical, Textile, Pharmaceutical, Pulp & Paper, Mining, Boiler and Power Industries
Technical Parameters
Installation

Make sure that the pipe is free of impurities.
It is recommended to install the solenoid in vertical position with the coil facing upwards.

Application
Production Flow
About COVNA

COVNA Automation is one of the professional manufacturer of automatic control valves in Dongguan, China. Our products applied for food & beverage, water & wastewater, ultra pure water, desalination, chemical, textile, transportation, pulp & paper, mining, boiler and power industries.

COVNA Top Sales Team

Outward Bound Activity

COVNA is warmly popular all over the world and it's certified by TUV, SGS, RoHS, ISO 9001 for the entire process of design and manufacture of valves.

Packing

Packing: 2 inch 3 Way L Port 24V Stainless Steel Motorized Ball Valve packed with foam in carton.

Delivery Time: 7 working days after payment confirmed.
