Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Brand
-
Model Number:
-
DS-2CD2387G2P-LSU/SL
-
Style:
-
Turret
-
Video Compression Format:
-
H
-
Product name:
-
turret ip security camera
-
Lens:
-
2.8mm
-
motion detection:
-
yes
-
Effective Pixels:
-
Max. 2592(H)*1944 (V)
-
fps:
-
25
-
app:
-
sadp 4200
-
IR Distance(m):
-
15 to 30 m
-
nvr:
-
plug in play with hik nvr VISION
Quick Details
-
Special Features:
-
NIGHT VISION, Motion Detection, MIC
-
Function:
-
Wide Angle, NIGHT VISION
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM, Software reengineering
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Brand
-
Model Number:
-
DS-2CD2387G2P-LSU/SL
-
Style:
-
Turret
-
Video Compression Format:
-
H
-
Product name:
-
turret ip security camera
-
Lens:
-
2.8mm
-
motion detection:
-
yes
-
Effective Pixels:
-
Max. 2592(H)*1944 (V)
-
fps:
-
25
-
app:
-
sadp 4200
-
IR Distance(m):
-
15 to 30 m
-
nvr:
-
plug in play with hik nvr VISION
Detailed Images
Product Description
High quality imaging with 8 MP resolution
One image that presents all the scenes covered by the camera
24/7 colorful imaging
Efficient H.265+ compression technology
Clear imaging against strong back light due to 130 dB WDR technology
Focus on human and vehicle classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Water and dust resistant (IP67)
|
Camera
|
|
|
Image Sensor
|
2 × 1/1.8" Progressive Scan CMOS
|
|
Max. Resolution
|
5120 × 1440
|
|
Min. Illumination
|
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
|
|
Shutter Time
|
1/3 s to 1/100, 000 s
|
|
Angle Adjustment
|
Pan: -30° to 30°, tilt: -75° to 75°
|
|
Lens
|
|
|
Lens Type
|
Fixed focal lens, Dual lens: 4 mm
|
|
Focal Length & FOV
|
Horizontal FOV: 180° ± 10°
Vertical FOV: 44° |
|
Lens Mount
|
M16
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.0
|
|
Depth of Field
|
3.6 m to ∞
|
|
DORI
|
|
|
DORI
|
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
|
|
Illuminator
|
|
|
Supplement Light Type
|
White Light
|
|
Supplement Light Range
|
Up to 30 m
|
|
Smart Supplement Light
|
Yes
|
|
Video
|
|
|
Main Stream
|
When WDR is On:
50 Hz: 12.5 fps (5120 × 1440) 60 Hz: 15 fps (5120 × 1440) When WDR is Off: 50 Hz: 20 fps (5120 × 1440) 60 Hz: 20 fps (5120 × 1440) |
|
Sub-Stream
|
When WDR is On:
50 Hz: 12.5 fps (1920 × 536, 960 × 272) 60 Hz: 15 fps (1920 × 536, 960 × 272) When WDR is Off: 50 Hz: 20 fps (1920 × 536, 960 × 272) 60 Hz: 20 fps (1920 × 536, 960 × 272) |
|
Video Compression
|
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
H.264 Type
|
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type
|
Main Profile
|
|
Bit Rate Control
|
CBR, VBR
|
|
Scalable Video Coding (SVC)
|
H.264 and H.265 encoding
|
|
Region of Interest (ROI)
|
1 fixed region(s) for main stream
|
|
Audio
|
|
|
Audio Type
|
Mono sound
|
|
Audio Compression
|
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
|
|
Audio Bit Rate
|
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps
(MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
|
Audio Sampling Rate
|
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
|
|
Environment Noise Filtering
|
Yes
|
|
Network
|
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS,
PPPoE, SNMP, WebSocket, WebSockets |
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
|
|
User/Host
|
Up to 32 users
3 user levels: administrator, operator, and user |
|
Security
|
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic
and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address) |
|
Network Storage
|
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR), NVR,
Together with high-end HIK memory card, memory card encryption and health detection are supported. |
|
Client
|
iVMS-4200, Hik-Connect, Hik-Central
|
|
Web Browser
|
Plug-in required live view: IE 10, IE 11 ,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+ |
|
|
|
|
Image Parameters Switch
|
Yes
|
|
Image Settings
|
saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client
software or web browser |
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Wide Dynamic Range (WDR)
|
130 dB
|
|
SNR
|
≥ 52 dB
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Interface
|
|
|
Ethernet Interface
|
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board Storage
|
Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256
GB |
|
Built-in Microphone
|
Yes
|
|
Built-in Speaker
|
Max. power consumption: 1.2 W, max. sound pressure: 10 cm: 95 dB
|
|
Audio
|
1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
|
Alarm
|
1 input, 1 output (max. 24 VDC, 1 A)
|
|
Reset Key
|
Yes
|
|
Event
|
|
|
Basic Event
|
Motion detection (support alarm triggering by specified target types (human and vehicle)), alarm input and output, flashing alarm
light output, audible alarm output, exception |
|
Smart Event
|
Line crossing detection, intrusion detection, region entrance detection, region exiting
detection (support alarm triggered by specified target types (human and vehicle)), scene change detection |
|
Linkage
|
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, trigger capture, audible warning, white light flashing |
|
Deep Learning Function
|
|
|
Perimeter Protection
|
Line crossing, intrusion, region entrance, region exiting (support alarm triggering by
specified target types (human and vehicle)) |
|
General
|
|
|
Power
|
12 VDC ± 25%, 0.79 A, max. 9.5 W, Ø5.5 mm coaxial power plug,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.29 A to 0.18 A, max. 10.5 W |
|
Material
|
Base: metal, cover: metal
|
|
Dimension
|
Ø155 mm × 155.3 mm (Ø6.1" × 6.1")
|
|
Package Dimension
|
230 mm × 230 mm × 230 mm (9" × 9" × 9")
|
|
Weight
|
Approx. 1110 g (2.4 lb.)
|
|
With Package Weight
|
Approx. 1900 g (4.2 lb.)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating
Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Language
|
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch,
Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
|
General Function
|
Anti-flicker, heartbeat, password reset via email, password protection, one-key reset
|
|
Flashing Light
|
Yes
|
|
Approval
|
|
|
EMC
|
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7 |
|
Safety
|
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 |
|
Environment
|
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 |
|
Protection
|
IP67: IEC 60529-2013
|
|
Available Model
DS-2CD2387G2P-LSU/SL (4 mm) |
|
|
Level
|
Description
|
|
Top-level protection
|
HIK products at this level are equipped for use in areas where professional
anti-corrosion protection is a must. Typical application scenarios include coastlines, docks, chemical plants, and more. |
|
Moderate protection
|
HIK products at this level are equipped for use in areas with moderate
anti-corrosion demands. Typical application scenarios include coastal areas about 2 kilometers (1.24 miles) away from coastlines, as well as areas affected by acid rain. |
|
No specific protection
|
HIK products at this level are equipped for use in areas where no specific
anti-corrosion protection is needed. |
