Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
ZHE
-
Product name:
-
Electric Winch
-
Motor:
-
6.0hp/4.5kw 24V, Series Wound motor
-
Fairlead:
-
Aluminum Fairlead
-
Voltage:
-
12/24v
-
Weight:
-
28KG
-
Packing:
-
1 Pcs/carton
Quick Details
-
Power Source:
-
Electric
-
Application:
-
ATV/UTV
-
Capacity:
-
5443kg, 12000LBS (5443kgs) Single Line
-
Warranty:
-
1 year
-
Place of Origin:
-
ZHE
-
Product name:
-
Electric Winch
-
Motor:
-
6.0hp/4.5kw 24V, Series Wound motor
-
Fairlead:
-
Aluminum Fairlead
-
Voltage:
-
12/24v
-
Weight:
-
28KG
-
Packing:
-
1 Pcs/carton
Product Description
Rated Line Pull: 12000LB(5443kg) single-line;
Motor: 6.0hp/4.5kw 24V, Series Wound motor;
Gear Train: 3-stage planetary;
Gear Reduction Ratio: 216:1;
Clutch: Up and down 90°;
Cable :(φ9.5mm×26m);
Drum Size: φ2.51"×8.82"(φ64mm×224mm);
Overall Dimensions: (L×W×H)21.1"×6.4"×6.7"(535x162x170mm);
Gross Weight: 62.3lbs(28.3kg);
Duty Cycle: Intermittently;
fairlead: aluminium fairlead;
Package: 1pc/box, 565X210X345mm;
Mounting Bolt Pattern: 10"x4.5"(254mm×114.3mm);
Remote Control: Included;
Specification
|
item
|
value
|
|
Warranty
|
1 year
|
|
Customized support
|
OEM, ODM, OBM, Software reengineering
|
|
Place of Origin
|
ZHE
|
|
Power Source
|
Electric
|
|
Application
|
ATV/UTV
|
|
Capacity
|
5443kg
|
|
Product name
|
Electric Winch
|
|
Motor
|
6.0hp/4.5kw 24V, Series Wound motor
|
|
Fairlead
|
Aluminum Fairlead
|
|
Capacity
|
12000LBS (5443kgs) Single Line
|
|
Voltage
|
12/24v
|
|
Weight
|
28KG
|
|
Packing
|
1 Pcs/carton
|
Packing & Delivery
Carton
