Quick Details
-
Coil Number:
-
AUTOTRANSFORMER
-
Place of Origin:
-
China
-
Brand Name:
-
ZHIBO
-
Model Number:
-
HSSP
-
frequency:
-
50/60Hz
-
standard:
-
IEC60076
-
No. of phase:
-
single/ three phases
-
winding material:
-
copper or alumnium
-
Rated Power:
-
50~55000kVA
-
Voltage:
-
6.3~66kV
-
Product name:
-
Three Phase Transformer
-
Core Material:
-
Cold Rolled Grain Oriented Silicon Steel
-
Package:
-
plywooden or nude suitable to be delivered
-
service condition:
-
indoor or outdoor
Quick Details
-
Usage:
-
RECTIFIER
-
Phase:
-
Three
-
Coil Structure:
-
TOROIDAL
-
Coil Number:
-
AUTOTRANSFORMER
-
Place of Origin:
-
China
-
Brand Name:
-
ZHIBO
-
Model Number:
-
HSSP
-
frequency:
-
50/60Hz
-
standard:
-
IEC60076
-
No. of phase:
-
single/ three phases
-
winding material:
-
copper or alumnium
-
Rated Power:
-
50~55000kVA
-
Voltage:
-
6.3~66kV
-
Product name:
-
Three Phase Transformer
-
Core Material:
-
Cold Rolled Grain Oriented Silicon Steel
-
Package:
-
plywooden or nude suitable to be delivered
-
service condition:
-
indoor or outdoor
Quick details:
|
Brand Name: |
ZHIBO |
|
Model Number: |
HSSP series of 10KV, 35KV |
|
Certification: |
ISO9001 |
|
Place of Origin: |
China |
Custom attributes:
|
Product Name : |
HSSP series of 10KV, 35KV |
Installation : |
Indoor /Outdoor |
|
Rated Capacity : |
4000~55000KVA |
Voltage : |
6kv-35kv |
|
Number of Phases : |
Three Phases |
Frequency : |
50Hz/60Hz |
|
Cooling : |
ONAN/ONAF |
Coil : |
Copper/Aluminum Coil |
|
Insulation level : |
Class H/F |
Core : |
Cold Rolled Grain Oriented Silicon Steel Sheet |
Product commerce clause:
|
Minimum Order Quantity: |
1Unit |
|
Price: |
negotiation |
|
Payment Terms: |
T/T ;L/C;USD |
|
Supply Ability: |
500 units per month |
|
Delivery Time: |
20 working days after received your payment |
|
Packaging Details: |
wooden box |
Description:
Furnace series include electric arc furnace transformer, ladle refining furnace transformer, electroslag furnace transformer, submerged arc furnace with (ferroalloy, calcium carbide furnace, phosphorus furnace, etc.) transformers, frequency induction furnace transformers of various AC furnace transformer. Industrial furnace transformer means refining furnace transformer power supply transformer, which is based on the load characteristics and operating characteristics of various furnace designed for dedicated transformer.
Product Features:
1. Saving area occupied by the equipment. On a three phase three pillar core, each column is equipped with more than two sets of high and low voltage coil; the single group (table) can be used, and you can also use multi -group (table).
2. The transformer has two or more sets of low voltage coil, each group may be used alone, which may also be used in parallel. There is a large short-circuit impedance in the coil.
3. It is usually used by VVVF motor or connects DC motor after rectification. It can use the "one machine, multi changes" or multi -machine, one change" wiring.
4. Widely used in electric, traction, drive, DC transmission, electroplating, excitation, cascade speed control, electrolytic and electrostatic dust various industries.
Technical parameter:
