Quick Details
-
Warranty:
-
25 Years, 25 Year Linear Power
-
Brand Name:
-
Longi
-
Model Number:
-
LR5-72HPH 540-560M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Product name:
-
Longi Solar Panels
-
Power:
-
540-560W
-
Cell Type:
-
Monocrystalline
-
No. of Cells:
-
144
-
Weight:
-
27.5 Kg
-
Frame:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Single Glass,3.2mm Coated Tempered Glass
-
J-box:
-
IP 68 ,Three diodes
-
Output Cable:
-
+400,-200mm/±1400mm
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.7%
-
Warranty:
-
25 Years, 25 Year Linear Power
-
Brand Name:
-
Longi
-
Model Number:
-
LR5-72HPH 540-560M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Product name:
-
Longi Solar Panels
-
Power:
-
540-560W
-
Cell Type:
-
Monocrystalline
-
No. of Cells:
-
144
-
Weight:
-
27.5 Kg
-
Frame:
-
Anodized Aluminium Alloy
-
Front Glass:
-
Single Glass,3.2mm Coated Tempered Glass
-
J-box:
-
IP 68 ,Three diodes
-
Output Cable:
-
+400,-200mm/±1400mm
Product Description
Our high-efficiency PV modules are widely used all over the world, from alpine grasslands to desert wastelands, and from ponds and vegetable beds to household dwellings.
**Suitable for ground power plants and distributed projects
**Advanced module technology delivers superior module efficiency
**
Excellent outdoor power generation performance
**
High module quality ensures long-term reliability
Why choose LONGi
1. Hi-MO 54c has an industry standardized size, which is conducive to the system costs caused by the standardization of brackets
and inverters. The size and weight of module are suitable for single person handling, and the operation and installation are
convenient, and it is perfectly suitable for 15A string inverter.
2. LONGi has the largest module production capacity in the industry, with more than 65 GW in its integrated capacity network fully
guaranteeing the supply of modules. In addition, the production network facilitates the global distribution of modules with the
help of land transportation, railway transportation and sea transportation.
3. LONGi launched Life-cycle Standards to guarantee the whole life-cycel quality. LONGi's Integrated capacity layout can guarantee
the traceability of each module, and our highly automated production lines feature end-to-end inspection and analysis processes to
ensure that each module meets the highest quality standards. We select module materials according to the highest standards, with
the requirement that all new materials be subject to extended qualification and reliability tests before being incorporated into
our products. Third-party labs like RETC and PVEL have ranked our modules among the highest quality products on the market.
and inverters. The size and weight of module are suitable for single person handling, and the operation and installation are
convenient, and it is perfectly suitable for 15A string inverter.
2. LONGi has the largest module production capacity in the industry, with more than 65 GW in its integrated capacity network fully
guaranteeing the supply of modules. In addition, the production network facilitates the global distribution of modules with the
help of land transportation, railway transportation and sea transportation.
3. LONGi launched Life-cycle Standards to guarantee the whole life-cycel quality. LONGi's Integrated capacity layout can guarantee
the traceability of each module, and our highly automated production lines feature end-to-end inspection and analysis processes to
ensure that each module meets the highest quality standards. We select module materials according to the highest standards, with
the requirement that all new materials be subject to extended qualification and reliability tests before being incorporated into
our products. Third-party labs like RETC and PVEL have ranked our modules among the highest quality products on the market.
Specification
|
Module Type
|
LR5-72HPH 540M
|
LR5-72HPH 545M
|
LR5-72HPH 550M
|
LR5-72HPH 560M
|
|||
|
Module Efficiency
|
20.9%
|
21.1%
|
21.3%
|
21.7%
|
|||
|
Voltage Max Power
|
41.65V
|
41.8V
|
41.95V
|
42.25V
|
|||
|
Open Circuit Voltage
|
49.5V
|
49.65V
|
49.8V
|
50.1V
|
|||
|
Current Max Power
|
12.97A
|
13.04A
|
13.12A
|
13.26A
|
|||
|
Short Circuit Current
|
13.85A
|
13.92A
|
13.98A
|
14.10A
|
|||
|
Cell Type
|
P Type
|
|
|
|
|||
|
Dimension
|
2278*1134*35mm
|
|
|
|
|||
|
Weight
|
27.5kg
|
|
|
|
|||
|
Junction Box
|
IP68, three diodes
|
|
|
|
|||
|
Package
|
31pcs per pallet/155pcs per 20' GP / 620PCS per 40HQ
|
|
|
|
|||
|
Warranty
|
12 years warranty for materials and processing, 25 years warranty for extra linear power output
|
|
|
|
|||
