Quick Details
-
Warranty:
-
25YEARS, 25 years
-
Brand Name:
-
Alicosolar
-
Model Number:
-
AS-MO-100
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
790*765*30mm
-
Description:
-
100w solar panel
-
Keyword:
-
panel solar 100w
-
Frame:
-
Anodized aluminium alloy
-
Junction Box:
-
Ip 65 Rated/Past connector
-
Connectors:
-
MC 4 compatible IP67
-
Front Cover:
-
3.2mm high transimissiion,low Iron tempered glass
-
Certificate:
-
CE/TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Bifacial, Double-glass, All Black, HJT, N-TYPE, TOPCON, Mono
-
Panel Efficiency:
-
22%
-
Warranty:
-
25YEARS, 25 years
-
Brand Name:
-
Alicosolar
-
Model Number:
-
AS-MO-100
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
790*765*30mm
-
Description:
-
100w solar panel
-
Keyword:
-
panel solar 100w
-
Frame:
-
Anodized aluminium alloy
-
Junction Box:
-
Ip 65 Rated/Past connector
-
Connectors:
-
MC 4 compatible IP67
-
Front Cover:
-
3.2mm high transimissiion,low Iron tempered glass
-
Certificate:
-
CE/TUV
Product Description
Camping Small Size Mini Solar Panel 100W 6V 12V 18V 20W 30W 40W 50W 150W 50 Watt Custom Panel Solar For Outdoor Home
|
Model Number
|
AS40M-32
|
AS50M-32
|
AS60M-32
|
AS70M-32
|
AS75M-32
|
AS80M-32
|
|
Testing Condition
|
STC
|
STC
|
STC
|
STC
|
STC
|
STC
|
|
Maximum Power (Pmax/W)
|
40
|
50
|
60
|
70
|
75
|
80
|
|
Open Circuit Voltage (Voc/V)
|
21.28
|
21.42
|
22.06
|
21.51
|
21.8
|
22.06
|
|
Short Circuit Current (Isc/A)
|
2.34
|
2.91
|
3.25
|
4.06
|
4.21
|
4.33
|
|
Voltage at Max Power (Vmp/V)
|
18.24
|
18.37
|
19.37
|
18.43
|
18.79
|
19.37
|
|
Current at Max Power (Imp/A)
|
2.19
|
2.72
|
3.10
|
3.8
|
3.89
|
4.13
|
|
Module Weight (Kg)
|
2.8
|
3.43
|
3.43
|
4.53
|
4.53
|
4.53
|
|
Module Dimension (mm)
|
655*395*30
|
800*395*30
|
800*395*30
|
545*765*30
|
545*765*30
|
545*765*30
|
|
Model Number
|
AS90M-32
|
AS95M-32
|
AS100M-32
|
AS110M-32
|
AS120M-32
|
AS130M-32
|
|
Testing Condition
|
STC
|
STC
|
STC
|
STC
|
STC
|
STC
|
|
Maximum Power (Pmax/W)
|
90
|
95
|
100
|
110
|
120
|
130
|
|
Open Circuit Voltage (Voc/V)
|
21.8
|
22.06
|
21.42
|
21.72
|
22.08
|
21.71
|
|
Short Circuit Current (Isc/A)
|
5.05
|
5.14
|
5.82
|
6.24
|
6.18
|
7.39
|
|
Voltage at Max Power (Vmp/V)
|
18.79
|
19.37
|
18.37
|
18.63
|
19.41
|
18.6
|
|
Current at Max Power (Imp/A)
|
4.79
|
4.9
|
5.44
|
5.9
|
6.18
|
6.99
|
|
Module Weight (Kg)
|
5.32
|
5.32
|
6.52
|
6.52
|
6.52
|
7.77
|
|
Module Dimension (mm)
|
640*765*30
|
640*765*30
|
785*765*30
|
785*765*30
|
785*765*30
|
785*765*30
|
