- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
MR18-29C
-
Dimension:
-
18 inch
-
Storage:
-
-
-
SNR:
-
-
-
Output Power:
-
1200W
-
Shell Material:
-
aluminium
-
Format:
-
-
-
The body material:
-
-
-
Nominal Diameter:
-
470mm/18inch
-
Nominal Impedance:
-
8Ω
-
AES Power Handing:
-
1200W
-
Maximum Power:
-
2400W
-
Sensitivity 1W/1M:
-
94dB
-
Frequency Range:
-
40-2.3kHZ
-
Voice Coil Diameter:
-
inside and outside 125.1mm/4.91 inch
-
Windinig Material:
-
Copper
-
Winding Depth:
-
27mm
-
Name:
-
18 inch speaker
Quick Details
-
Warranty:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MERRY AUDIO
-
Model Number:
-
MR18-29C
-
Dimension:
-
18 inch
-
Storage:
-
-
-
SNR:
-
-
-
Output Power:
-
1200W
-
Shell Material:
-
aluminium
-
Format:
-
-
-
The body material:
-
-
-
Nominal Diameter:
-
470mm/18inch
-
Nominal Impedance:
-
8Ω
-
AES Power Handing:
-
1200W
-
Maximum Power:
-
2400W
-
Sensitivity 1W/1M:
-
94dB
-
Frequency Range:
-
40-2.3kHZ
-
Voice Coil Diameter:
-
inside and outside 125.1mm/4.91 inch
-
Windinig Material:
-
Copper
-
Winding Depth:
-
27mm
-
Name:
-
18 inch speaker
Products Description
|
Thiele & Small Parameters 参数
|
|
|
|
|
|
|||
|
Resonance Frequency
|
|
共振频率
|
|
Fs
|
40Hz
|
|||
|
DC Resistance
|
|
直流电阻
|
|
Re
|
6.35Ω
|
|||
|
Mechanical Factor
|
|
机械品质因数值
|
|
Qms
|
30.3
|
|||
|
Electrical Factor
|
|
电品质因数值
|
|
Qes
|
0.42
|
|||
|
Total Factor
|
|
总品质因数值
|
|
Qts
|
0.42
|
|||
|
BL Factor
|
|
磁力
|
|
BL
|
35.1T.m
|
|||
|
Effective Moving Mass
|
|
有效移动质量
|
|
Mms
|
325.7g
|
|||
|
Compliance
|
|
力顺
|
|
Cms
|
0.05MM/N
|
|||
|
Equivalent Cas Air Load
|
|
有效容积
|
|
Vas
|
98.9L
|
|||
|
Effettive Piston Area
|
|
振动面积(有效活塞面积)
|
|
Sd
|
1194.6cm²
|
|||
|
η(Eta Zero)
|
|
扬声器效率
|
|
η0
|
1.43%
|
|||
|
Mountiong & Shipping Information
|
|
|
|
|
|
|||
|
Overall Diameter
|
|
外径
|
|
|
470mm
|
|||
|
Bolt circle diameter
|
|
安装孔径
|
|
|
445mm
|
|||
|
Baffle Cutout Diameter
|
|
面板开孔径
|
|
|
430mm
|
|||
|
Depth
|
|
高度
|
|
|
230mm
|
|||
|
Net Weight
|
|
净重
|
|
|
24.68KG
|
|||
|
Shipping Weight
|
|
毛重
|
|
|
24.9KG
|
|||
|
Shipping Box(Single)
|
|
单包装尺寸
|
|
|
47*47*25cm
|
|||
