Quick Details
-
Model Number:
-
60ASF-M04030
-
Frequency:
-
50/60Hz
-
Rated Power:
-
400W
-
Rated Voltage:
-
220V
-
Rated Current:
-
2.6A
-
RPM:
-
3000
-
Holding Torque:
-
1.27Nm
-
Peak Torque:
-
5.08Nm
-
Voltage Constant:
-
33 V/1000r/min
-
Torque Coefficient:
-
0.49 N.M/A
-
Rotor Inertia:
-
0.56*10-4 Kg.m2
-
Weight:
-
1.16KG
Quick Details
-
AC Voltage:
-
208-230 / 240 V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
EMTECH
-
Model Number:
-
60ASF-M04030
-
Frequency:
-
50/60Hz
-
Rated Power:
-
400W
-
Rated Voltage:
-
220V
-
Rated Current:
-
2.6A
-
RPM:
-
3000
-
Holding Torque:
-
1.27Nm
-
Peak Torque:
-
5.08Nm
-
Voltage Constant:
-
33 V/1000r/min
-
Torque Coefficient:
-
0.49 N.M/A
-
Rotor Inertia:
-
0.56*10-4 Kg.m2
-
Weight:
-
1.16KG
Product Description
Installation Dimension
|
Model
|
80ASF-M04030
|
80ASF-M07530
|
80ASF-M09530
|
80ASF-M10025
|
|
L（mm）
|
131
|
146
|
158
|
158
|
GENERAL SPECIFICATIONS
|
Motor Model
|
80ASF-M04030
|
80ASF-M07530
|
80ASF-M09530
|
80ASF-M10025
|
|||
|
Rated Power(KW)
|
0.4
|
0.75
|
0.95
|
1
|
|||
|
Rated Voltage(V)
|
220
|
220
|
220
|
220
|
|||
|
Rated Current(A)
|
2
|
3
|
3
|
4.4
|
|||
|
Rated Speed(RPM)
|
3000
|
3000
|
3000
|
2500
|
|||
|
Holding Torque(N.M)
|
1.27
|
2.5
|
2.8
|
4.5
|
|||
|
Peak Torque(N.M)
|
3.8
|
7.5
|
8.4
|
11.5
|
|||
|
Voltage Constant(V/1000r/min)
|
40
|
48
|
60
|
65
|
|||
|
Torque Coefficient(N.M/A)
|
0.64
|
0.83
|
0.94
|
1.02
|
|||
|
Rotor Inertia(Kg.m2)
|
0.95×10
-4
|
1.12×10
-4
|
1.36×10
-4
|
1.36×10
-4
|
|||
|
Line-Line Resistance(Ω)
|
2.15
|
2.78
|
3.24
|
3.41
|
|||
|
Line-Line Inductance(mH)
|
11.2
|
14.5
|
20
|
18.2
|
|||
|
Electrical Time Constant(Ms)
|
1.56
|
2.33
|
2.38
|
2.58
|
|||
|
Weight(Kg)
|
1.83
|
2.85
|
3.97
|
3.88
|
|||
|
Encoder Line Number(PPR)
|
2500
|
|
|
|
|||
|
Insulation Class
|
Class F
|
|
|
|
|||
|
Safety Class
|
IP 65
|
|
|
|
|||
|
Working Enviroment
|
Temperature:-20℃～＋50℃ Humidity: Below 90% RH No dewing
|
|
|
|
|||
