Quick Details
-
Weight (KG):
-
2500
-
Voltage:
-
220V/380V
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YILONG
-
Dimension(L*W*H):
-
L4500*W2500*H3600mm
-
Machine type:
-
Automatic Bag Filling Packaging Equipment
-
Capacity:
-
10-90 bag/min According to the product character
-
Scope of application:
-
Peanut,jujube,potato chips,crust,nuts,confectionery,fried food,gum,etc
-
pouch size:
-
W: 80-270mm L: 100-380mm
-
Machine size:
-
L4500*W2500*H3600mm
-
Safety system:
-
Advanced alarm system
-
structure:
-
Mechanical mechanism No Pneumatic structure
-
Pouch style:
-
Stand up pouch,Flat pouch,PE pouch,Gusset pouch, Zipper pouch,etc
-
Marketing Type:
-
Hot Product
Quick Details
-
Function:
-
Capping, FILLING, Labeling, Sealing, SLITTING, Wrapping
-
Packaging Type:
-
Foil, Pouch, Stand-up Pouch, zipper bags, eight-side sealed bags, Bags
-
Packaging Material:
-
Plastic, Paper, Other
-
Weight (KG):
-
2500
-
Voltage:
-
220V/380V
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YILONG
-
Dimension(L*W*H):
-
L4500*W2500*H3600mm
-
Machine type:
-
Automatic Bag Filling Packaging Equipment
-
Capacity:
-
10-90 bag/min According to the product character
-
Scope of application:
-
Peanut,jujube,potato chips,crust,nuts,confectionery,fried food,gum,etc
-
pouch size:
-
W: 80-270mm L: 100-380mm
-
Machine size:
-
L4500*W2500*H3600mm
-
Safety system:
-
Advanced alarm system
-
structure:
-
Mechanical mechanism No Pneumatic structure
-
Pouch style:
-
Stand up pouch,Flat pouch,PE pouch,Gusset pouch, Zipper pouch,etc
-
Marketing Type:
-
Hot Product
Product Function Introduction
|
Pre-made bag packing machine technical parameters
|
|
|
|
|
||||
|
Model
|
YL-8SW
|
YL-8SR
|
YL-8SS
|
YL-6SS
|
||||
|
Working station
|
8
|
8
|
8
|
6
|
||||
|
Bag length
|
100-350mm
|
100-300mm
|
100-380mm
|
140-380mm
|
||||
|
Bag width
|
80-305mm
|
100-200mm
|
130-270mm
|
140-260mm
|
||||
|
Packing speed
|
15-90
|
30-60
|
30-50
|
15-30
|
||||
|
Pouch style
|
flat pouch、stand up pouch、zipper pouch、flat pouch、back sealing pouch、special pouch
|
flat pouch、PE pouch
|
flat pouch、stand up pouch、zipper pouch
|
flat pouch、stand up pouch、PE pouch
|
||||
|
Voltage
|
380V/50HZ
|
380V/50HZ
|
380V/50HZ
|
380V/50HZ
|
||||
|
Power
|
2kw
|
1.5KW
|
2.5KW
|
1.5KW
|
||||
|
Air pressure
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
0.6-0.8
|
||||
|
Machine weight
|
1640kg
|
1370kg
|
1850kg
|
850kg
|
||||
|
Machine size
|
2760*2180*1500mm
|
1750*2180*1400mm
|
2800*2500*1420mm
|
1520*1830*1530mm
|
||||
Machine working process
ROTARY MACHINE' S WORK PROCESS
1.
Bag pick-up
2.Optional Zipper open and Date print3.Bag mouth and bottom open
4. Product fill 5.Option: Solid :Nitrogen charge,Powder:Bag mouth clean,
Liquid:Secondary filling 6.First seal 7.Second seal 8.Output
Working Process Of Whole Line For Packaging Machines
Product Application
Detailed Images
SIEMENS touch screen
Bag pick-up
Rotary table
Optional Zipper open and Date print
Bag mouth open
Product fill
Optional Bag mouth clean
Optional Down hammer
Two times seal
Optional
