Quick Details
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Model:
-
ZX-168
ZX-168 Pre-programming Length Controller
ZX-168 length controller (or meters) control length with the hall switch pickup driving guide roller of the material being tested running laps cumulative circumference of the guide roller itself. It can be widely used in printing, laminating, slitting, winding machines and other necessary length control device.
Main Features
★
Main part adopts SCM control
★
Easy to install with a compact
★
Data storage function once power off
★
The function of presetting length data controlling relay output
★
The function of presetting length early cycle alarm
Main Technical Parameters
|
Length measuring range |
0-999999m cumulative manner |
|
Circumference input range |
0.0001-9.9999m |
|
Input signal type |
Hall proximity switches, contacts, photoelectric switch (NPN) |
|
Display digits |
6, LED decimal point automatically shift |
|
Output type |
A set of preset relay output, 1 group alarm output transistor in advance (DC12V) |
|
Power off deal |
Storage data more than five years |
|
Zero mode |
Operation panel keys, external switch, automatic |
|
Overall dimensions |
96×48×115(mm)(W×H×D) |
|
Installation sizes |
92×44×105(mm)(W×H×D) |
|
Work power |
DC 220V 50/60HZ |
|
Model No.
|
ZX-168
|
|
Range of measuring linear velocity
|
0-9999 turn/min multiply girth
|
|
Range of girth input
|
0.0001-9.9999 m
|
|
Type of input signal
|
Hall switch, contact, photoelectric switch(NPN)
|
|
Display digits
|
6, LED decimal point automatically shift
|
|
Output way
|
A set of preset relay output, 1 group alarm output transistor in advance (DC12V)
|
|
Power off deal
|
Storage data more than five years
|
|
Zero mode
|
Operation panel keys, external switch, automatic
|
|
Appearance size
|
96 ×48×115mm
|
|
Size of installing
|
92 ×44×105mm
|
|
Working voltage
|
220V+15% AC 50Hz
|
