Quick Details
-
Name:
-
Luxury Outdoor Sport Tent
-
Roof cover:
-
850gsm Double-coated PVC Fabric
-
Accessories:
-
Included
-
Material:
-
Aluminum Alloy GB6061-T6
-
Life Span:
-
15-20years
-
Shape:
-
A-frame
-
Certificates:
-
CE TUV
-
Cover material:
-
Double PVC-Coated Polyester
-
Warranty:
-
1 Year
-
Size:
-
Customized Size
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Shengyixin
-
Model Number:
-
tent
-
Name:
-
Luxury Outdoor Sport Tent
-
Roof cover:
-
850gsm Double-coated PVC Fabric
-
Accessories:
-
Included
-
Material:
-
Aluminum Alloy GB6061-T6
-
Life Span:
-
15-20years
-
Shape:
-
A-frame
-
Certificates:
-
CE TUV
-
Cover material:
-
Double PVC-Coated Polyester
-
Warranty:
-
1 Year
-
Size:
-
Customized Size
| Material | Product Code | Unit Space | Span | Eave Height | Total Height | Main Pipe Spec. | The tallest Pipe |
| Steel | SGP030303 | 3 | 3 | 3 | 3.6 | 40*60 | 3 |
| Steel | SGP030403 | 3 | 4 | 3 | 3.8 | 40*60 | 4 |
| Steel | SGP030503 | 3 | 5 | 3 | 4 | 40*60 | 5 |
| Steel | SGP030603 | 3 | 6 | 3 | 4 | 40*60 | 6 |
| Steel | SGP030803 | 3 | 8 | 3 | 4.4 | 40*60/50*70 | 4.3 |
| Steel | SGP031003 | 3 | 10 | 3 | 4.9 | 50*70 | 5.2 |
| Aluminium Alloy | SLP051003 | 5 | 10 | 3 | 4.6 | 48*100/68*122 | 5.2 |
| Aluminium Alloy | SLP051204 | 5 | 12 | 4 | 5.9 | 68*122 | 6.3 |
| Aluminium Alloy | SLP051504 | 5 | 15 | 4 | 6.4 | 88*166/108*150 | 8 |
| Aluminium Alloy | SLP051804 | 5 | 18 | 4 | 6.9 | 112*203 | 9.6 |
| Aluminium Alloy | SLP052004 | 5 | 20 | 4 | 7.25 | 112*203 | 10.6 |
| Aluminium Alloy | SLP052505 | 5 | 25 | 5 | 9 | 112*203 | 10.6 |
| Aluminium Alloy | SLP053005 | 5 | 30 | 5 | 9.8 | 113*259 | 10.6 |
| Aluminium Alloy | SLP053505 | 5 | 35 | 5 | 10.7 | 125*300 | 10.6 |
| Aluminium Alloy | SLP054005 | 5 | 40 | 5 | 11.5 | 128*300 | 11 |
| Aluminium Alloy | SLP055005 | 5 | 50 | 5 | 13.5 | 125*350 | 13.3 |
|
1.Peronal Design |
2.Real Material |
3.Durable
|
|
Fashion Product design,
Strong visual impaction |
Standrad Aluminum ally.
Double coated PVC polyester fire and water resistance fabric |
Precise joints and
careful details |
| 4.Custom |
5.Waterproof and
UV resistance |
6.Simple Build |
|
Wuxi manufacturer for
different span and colors |
Effective prevention of
rainwater and sunshine |
Assamble and disassemble
simply,easy for transport and storage |
Different specifications and colors can satisfy all requirements from customers.
(2)Permanent Solution; this method is adopted for long term appliance. The consolidation system is casting into the ground. It is very stable.
(3)Expandable Screw; for the ground, which maybe set the screw into the hard ground, like concrete ground.
(4)Anchor fix way, this is a method for the soft ground, like grass and muddy ground.
|
Requirement: ---------------------------------------------------------------------------------------------------
1. Width__________M
2. Length________M
3. Space distance between columns:________M
4. Eave high__________M
5. Brick wall or concrete wall high(if any)_________M
6. Roof slop grade___________(°or%)
7. Ventilation: 1)no 2)normal 3)natural 4)ventilator
8. Wall and roof: 1)EPS sandwich panel 2)PU panel 3) rockwool panel 4) steet sheet thickness:__________________
9. Door: 1)sandwich panel sliding door 2)rolling door size:__________________
10. Window: 1) aluminium window 2) pvc window size :_____________________
11. Lighting: 1) skylight board 2) thickness:__________
12. Draining: 1) natural draining 2) gutter
13. Crane: 1) yes 2) no 3) capacity_____T
|
