- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Leapion
-
Single Pulse Energy:
-
96J/150J
-
Pulse Width:
-
0.1~20MS
-
Wavelength:
-
1080nm
-
Focal Spot Diameter:
-
0.6-0.5nm
-
Dimensions:
-
115*73*109cmm
-
Weight (KG):
-
260 KG
-
Marketing Type:
-
Hot Product 2023
-
Core Components:
-
laser source
-
Product name:
-
laser welding machine 3 in 1
-
Application:
-
metal welding
-
Laser source:
-
RAYCUS/MAX
-
Laser power:
-
1000w/1500w/2000w
-
Welding head:
-
hanwei Handheld Welding Head
-
Laser wavelength:
-
1064nm Laser Soldering
-
Welding depth:
-
0.2-3mm(adjustable)
-
Cooling System:
-
Water Cooling
-
Welding Frequency:
-
220V/50Hz/40A Channel Letter Laser welding
-
Pse Frequency:
-
1-100HZ( Adjustable)
Quick Details
-
Max. Output Power:
-
3000W
-
Usage:
-
precision welding
-
Laser Source Brand:
-
MAX / Raycus / IPG
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Leapion
-
Single Pulse Energy:
-
96J/150J
-
Pulse Width:
-
0.1~20MS
-
Wavelength:
-
1080nm
-
Focal Spot Diameter:
-
0.6-0.5nm
-
Dimensions:
-
115*73*109cmm
-
Weight (KG):
-
260 KG
-
Marketing Type:
-
Hot Product 2023
-
Core Components:
-
laser source
-
Product name:
-
laser welding machine 3 in 1
-
Application:
-
metal welding
-
Laser source:
-
RAYCUS/MAX
-
Laser power:
-
1000w/1500w/2000w
-
Welding head:
-
hanwei Handheld Welding Head
-
Laser wavelength:
-
1064nm Laser Soldering
-
Welding depth:
-
0.2-3mm(adjustable)
-
Cooling System:
-
Water Cooling
-
Welding Frequency:
-
220V/50Hz/40A Channel Letter Laser welding
-
Pse Frequency:
-
1-100HZ( Adjustable)
Products Description
Industrial Machine Case
Laser System
Laser Head
Control System
Specification
|
Model
|
LW 3 in 1 Laser Welding Cutting Cleaning Machine
|
|
Laser Type
|
Fiber Laser
|
|
Fiber Laser Power
|
1000w, 1500w, 2000w, 3000w
|
|
Welding Width
|
0.2-5mm
|
|
Head Type
|
LightWeight Handheld
|
|
Cooling Type
|
Water Cooled
|
|
Laser Source Brand
|
Max, Raycus, IPG, Reci, Leapion, etc.
|
|
Control Panel
|
Touch Screen
|
|
Shell Material
|
Metal
|
Technical Parmaeters
|
Spot adjustment range
|
0-5mm
|
|
Effective light aperture
|
16mm
|
|
Laser Head Weight
|
0.71KG
|
|
Optical fiber interface
|
QBH
|
|
Wavelength range
|
1070±20nm
|
|
Intelligent protection function
|
Protective lens intelligent temperature control device
|
|
Collimating focal length
|
50mm
|
|
Focal length
|
150mm
|
|
Core diameter of supported wire
|
3.0mm
|
|
Maximum wire feed speed
|
80mm/s
|
|
Auto Wire Feeder Net Weight
|
16.2KG
|
|
Auto Wire Feeder Dimension
|
560*240*472mm
|
|
Machine Package Dimension
|
1150*880*1400mm
|
|
Machine Package Weight
|
250KG
|
Laser Welding Ability
