- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
GEYA
-
Model Number:
-
GYIS-N32/4
-
Max. Current:
-
63A
-
MOQ:
-
20pcs
-
Application:
-
Solar Pv System
-
Warranty:
-
18 Months
-
PAYMENT:
-
Paypal\TT\Western Union\ Trade Assurance
-
Ui:
-
1500V DC
-
Ue:
-
300-1200V DC
-
Ie:
-
9-32A
-
Protection degree:
-
IP66 Waterproof
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
1200V
-
Place of Origin:
-
ZHE
-
Brand Name:
-
GEYA
-
Model Number:
-
GYIS-N32/4
-
Max. Current:
-
63A
-
MOQ:
-
20pcs
-
Application:
-
Solar Pv System
-
Warranty:
-
18 Months
-
PAYMENT:
-
Paypal\TT\Western Union\ Trade Assurance
-
Ui:
-
1500V DC
-
Ue:
-
300-1200V DC
-
Ie:
-
9-32A
-
Protection degree:
-
IP66 Waterproof
Product Description
*Modular design, DC insulation voltage 1500V, compact structure, grade 2-8 optional
*The installation is firm and good sealing. The installation can make the whole machine reach IP66 level
*Convenient wiring and optional positive and negative contacts to meet different installation scenarios
*The high-speed "on-off" switching mechanism adopts energy storage spring to quickly realize switching, and the maximum on-off switching time is less than 5ms
*The contact self-cleaning design reduces the resistance and energy consumption of DC switch and prolongs the service life of switch
*Imported UL94V-0 flame retardant material is adopted, which can work under full load in the range of - 40 ℃ ~ + 70 ℃
*It has passed the test of IEC / en60947-3:2009 + A1 + A2, as60947.3, ul508i, G-B / t14048.3 and is certified by TUV, CE, CB, SAA, UL and CCC
*IP66 protection grade
*The knob can be locked to prevent mis-operation
*The maximum on-off switching time is less than 3MS
*Ui:1500VDC
*Ue:300~1200VDC
*Ie:9~32A
Specification
|
item
|
value
|
|
Certification
|
TUV
|
|
Whether the smart
|
No
|
|
Place of Origin
|
ZHE
|
|
Brand Name
|
GEYA
|
|
Model Number
|
GYIS-N32/4
|
|
Max. Current
|
63A
|
|
Max. Voltage
|
1200V
|
|
MOQ
|
20pcs
|
|
Application
|
Solar Pv System
|
|
Warranty
|
18 Months
|
|
PAYMENT
|
Paypal\TT\Western Union\ Trade Assurance
|
|
Ui
|
1500V DC
|
|
Ue
|
300-1200V DC
|
|
Ie
|
9-32A
|
|
Protection degree
|
IP66 Waterproof
|
