Quick Details
-
Dimension(L*W*H):
-
810*710*1410
-
Weight:
-
850 KG
-
Function:
-
Produce Bopp Packing Tape
-
Usage:
-
Coating Materials
-
Keywords:
-
High Efficiency Film Coating Machine
-
Material:
-
Stainess Steel
-
Apllication:
-
Protection Labe
-
Capacity:
-
6~30
-
Speed of drum:
-
0.75-2.2
-
Color:
-
Stainess Steel Color
-
Marketing Type:
-
Ordinary Product
Quick Details
-
Voltage:
-
380v~440v
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ROYAL
-
Dimension(L*W*H):
-
810*710*1410
-
Weight:
-
850 KG
-
Function:
-
Produce Bopp Packing Tape
-
Usage:
-
Coating Materials
-
Keywords:
-
High Efficiency Film Coating Machine
-
Material:
-
Stainess Steel
-
Apllication:
-
Protection Labe
-
Capacity:
-
6~30
-
Speed of drum:
-
0.75-2.2
-
Color:
-
Stainess Steel Color
-
Marketing Type:
-
Ordinary Product
Characteristic:
Peristaltic pump with constant pressure variable, eliminate return pipe.
Display with touch screen.
Expanded PLC module, all parameters are set in control panel.
Sound and heat insulation, it has temperature insulation effect to inside of machine.
Operate at seal and negative pressure state.
Nozzle ( from Japan ) -uniform atomizing, big area of spraying, adjustable direction, the nozzle has no dropping leakage and block.
Promote material to stir aslant and writhe . The exchanging frequency is frequency. Therefore it can raise the rate of finished product .
|
Specification
/ Item |
RYBGB-5
|
RYBGB-40
|
RYBGB-80
|
RYBGB-150
|
||||
|
|
5
|
40
|
80
|
150
|
||||
|
Capacity(kg/batch)
|
6~30
|
6~30
|
3-15
|
3-15
|
||||
|
Speed of drum(rpm)
|
0.75
|
1.1
|
1.5
|
2.2
|
||||
|
Power of motor for high efficiency filtering hot air(kw)
|
0.35
|
0.55
|
1.1
|
1.5
|
||||
|
Power of motor for high efficiency filtering hot air(kw)
|
2.2
|
3
|
3
|
5.5
|
||||
|
Power of motor for dust removing and air exhaust
|
810×710×1410
|
1000×800×1600
|
1250×990×1880
|
1570×1260×2066
|
||||
|
All datas are for reference only. According to the condition of material,our factory has the right change but not notice, pardon.
|
|
|
|
|
||||
