Quick Details
-
Ejection Stroke(mm):
-
120 mm
-
Place of Origin:
-
Anhui,China(mainland)
-
Brand Name:
-
LONGHUA
-
Voltage:
-
220v,380v
-
Dimension(L*W*H):
-
7.7*2.1*3.1
-
Year:
-
2023
-
Weight (KG):
-
20000
-
Power (kW):
-
22
-
Clamping Force (kN):
-
4500kN
-
Open Stroke(mm):
-
580mm
-
Space between Tie Bars(mm):
-
760*660
-
Diameter of Bars(mm):
-
130mm
-
Casting Force(kN):
-
450kN
-
Casting Stroke(mm):
-
580mm
-
Casting Pressure(MPa):
-
135MPa
-
Application:
-
Casting Industries
-
Function:
-
Die Casting Aluminum
-
Technology:
-
Die Casting Technology
-
Control system:
-
Computer Control
-
Type:
-
Hydraulic
-
Advantage:
-
High Quanlity
-
Chamber:
-
Cold Chamber Die Castng Machine
-
Configuration:
-
High Configuration
-
Material:
-
Die Casting Machine Carbon Steel
-
After-sales Service Provided:
-
Field installation, commissioning and training
Quick Details
-
Max.Thickness of Die Block (mm):
-
800 mm
-
Min.Thickness of Die Block (mm):
-
320 mm
-
Ejection Force(kN):
-
240 kN
-
Ejection Stroke(mm):
-
120 mm
-
Place of Origin:
-
Anhui,China(mainland)
-
Brand Name:
-
LONGHUA
-
Voltage:
-
220v,380v
-
Dimension(L*W*H):
-
7.7*2.1*3.1
-
Year:
-
2023
-
Weight (KG):
-
20000
-
Power (kW):
-
22
-
Clamping Force (kN):
-
4500kN
-
Open Stroke(mm):
-
580mm
-
Space between Tie Bars(mm):
-
760*660
-
Diameter of Bars(mm):
-
130mm
-
Casting Force(kN):
-
450kN
-
Casting Stroke(mm):
-
580mm
-
Casting Pressure(MPa):
-
135MPa
-
Application:
-
Casting Industries
-
Function:
-
Die Casting Aluminum
-
Technology:
-
Die Casting Technology
-
Control system:
-
Computer Control
-
Type:
-
Hydraulic
-
Advantage:
-
High Quanlity
-
Chamber:
-
Cold Chamber Die Castng Machine
-
Configuration:
-
High Configuration
-
Material:
-
Die Casting Machine Carbon Steel
-
After-sales Service Provided:
-
Field installation, commissioning and training
|
ITEMS
|
Unit
|
Specification
|
|
Clamping Force
|
KN
|
4500
|
|
Opening stroke
|
mm
|
580
|
|
Die thickness(Min--Max)
|
mm
|
320～800
|
|
Space between tie bars
|
mm
|
760*660
|
|
Ejector stroke
|
mm
|
120
|
|
Ejector force
|
KN
|
240
|
|
Injection position（0 as center）
|
mm
|
0，-220
|
|
Injection force（intensification)
|
KN
|
450
|
|
Injection stroke
|
mm
|
580
|
|
Plunger diameter
|
mm
|
￠70 ￠80 ￠90
|
|
lnjection weight(aluminum)
|
Kg
|
6.9
|
|
Casting pressure (intensification)
|
MPa
|
135/117/92
|
|
Max. casting area(40Mpa)
|
CM2
|
1250
|
|
Injection plunger penetration
|
mm
|
250
|
|
Diameter of pressure chamber flange
|
mm
|
130
|
|
Height of pressure chamber flange
|
mm
|
15
|
|
Max.working pressure
|
MPa
|
14
|
|
Motor power
|
Kw
|
22
|
|
Dimensions (L*W*H)
|
m
|
7.7*2.1*3.1
|
|
Machine lifting reference weight
|
T
|
20
|
|
Oil tank capacity
|
L
|
1000
|
We reserve the right to make any technical improvement without further notice
