Quick Details
-
Model Number:
-
Cameron Type FLS-R
-
Brand Name:
-
YCPT
-
Temperature rating:
-
-46℃-121℃
-
Working pressure:
-
2000psi-5000psi
-
Size:
-
2",3",4",5"
-
Connection type:
-
flange,union,thread,weld
-
Material class:
-
AA~HH
-
Certificate:
-
ISO9001:2000 CE
-
Type:
-
Gate Valves
Quick Details
-
Port Size:
-
all sizes, all size available
-
Warranty:
-
1 years
-
Place of Origin:
-
Shandong, China
-
Model Number:
-
Cameron Type FLS-R
-
Brand Name:
-
YCPT
-
Temperature rating:
-
-46℃-121℃
-
Working pressure:
-
2000psi-5000psi
-
Size:
-
2",3",4",5"
-
Connection type:
-
flange,union,thread,weld
-
Material class:
-
AA~HH
-
Certificate:
-
ISO9001:2000 CE
-
Type:
-
Gate Valves
Product Description
Application:
Mud pump line, standpipe manifolds, oil and gas pipelines, abrasive drilling mud system, corrosive water flood lines, cementing services, wellheads, well treating chemicals.
Specification
Specifications:
* Designed specifically for abrasive and erosive condition
* Gates available: Nickel-plated carbon steel, Monel, Aluminum Bronze or Stainless Steel
* Stainless or Carbon Steel Inserts with Nitrile or HNBR Elastomer
* Connection: Flange/Thread/Butt weld/Hammer Union
* Pressure ratings up to 5,000 psi in 2", 3", 4", 5" x 4" and 6" x 4" Valve Sizes
* Working Temperature: -46°C ~ +121°C
* Sour Service Models to NACE MR-01-75
* Specification Level: PSL1 ~ PSL3
* Performance Requirement: PR1 ~ PR2
* Factory Pressure Tested in Accordance with API.6A
* Gates available: Nickel-plated carbon steel, Monel, Aluminum Bronze or Stainless Steel
* Stainless or Carbon Steel Inserts with Nitrile or HNBR Elastomer
* Connection: Flange/Thread/Butt weld/Hammer Union
* Pressure ratings up to 5,000 psi in 2", 3", 4", 5" x 4" and 6" x 4" Valve Sizes
* Working Temperature: -46°C ~ +121°C
* Sour Service Models to NACE MR-01-75
* Specification Level: PSL1 ~ PSL3
* Performance Requirement: PR1 ~ PR2
* Factory Pressure Tested in Accordance with API.6A
Packing & Delivery
As per standard export package
