Quick Details
-
Model Number:
-
GLL
-
Max. Current:
-
100A
-
Product name:
-
Closed Type Load Switch
-
Rated current:
-
100A
-
Rated Themal Current:
-
25/32/40/63/80/100A
-
Mechanical Life:
-
10000 Times
-
Standard:
-
GB10963/IEC60898
-
Material:
-
Pa66 DMC and red copper T3
-
peculiarity:
-
Fair tetardant V0
-
Structure:
-
customized
-
Usage:
-
Low voltage
-
Keyword:
-
Closed Type Load Switch
-
Certification:
-
/
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LOVADON
-
Model Number:
-
GLL
-
Max. Current:
-
100A
-
Product name:
-
Closed Type Load Switch
-
Rated current:
-
100A
-
Rated Themal Current:
-
25/32/40/63/80/100A
-
Mechanical Life:
-
10000 Times
-
Standard:
-
GB10963/IEC60898
-
Material:
-
Pa66 DMC and red copper T3
-
peculiarity:
-
Fair tetardant V0
-
Structure:
-
customized
-
Usage:
-
Low voltage
-
Keyword:
-
Closed Type Load Switch
-
Certification:
-
/
380V Electrical Load Break Switch 32A 4P D11 Closed Type Load Switch
D11 is my company imported advanced technology to develop the most reliable performance of small volume, load breakers switch suitable for air-conditioning and ventilation system, water pump, suitable for industrial equipment, safety switch and used as insulation switches, equivalent to isolate KG20 overseas distribution circuit breaker KG100 - type load switch.
| Type | Outline dimension(mm) | Installation dimension(mm) | |||||||
| D3 | D4 | M | N | P | A1 | A2 | B | D2 | |
| D11-20/3 | 23 | 19 | 85 | 80 | 120 | 110 | - | - | 4.1 |
| D11-32/3 | 23 | 19 | 85 | 80 | 120 | 110 | - | - | 4.1 |
| D11-40/3 | 29 | 23 | 91 | 91 | 160 | 178 | - | - | 4.1 |
| D11-63/3 | 29 | 23 | 91 | 91 | 160 | 178 | - | - | 4.1 |
| D11-80/3 | 37.5 | 23 | 100 | 100 | 250 | 124 | 124 | 4.1 | |
| D11-20/6 | 29 | 23 | 91 | 91 | 160 | 178 | - | - | 4.1 |
| D11-32/6 | 29 | 23 | 91 | 91 | 160 | 178 | - | - | 4.1 |
| D11-40/6 | 37.5 | 23 | 100 | 91 | 160 | 124 | 124 | 4.1 | |
| D11-63/6 | 37.5 | 23 | 100 | 100 | 250 | 124 | 124 | 4.1 | |
| D11-80/6 | 50 | 23 | 89 | 83 | 156 | 150 | 150 | 150 | 7.5 |
