meaterial:0.7-1.2mm
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RFM
-
Voltage:
-
380V 50Hz 3phases or customer request
-
Power:
-
7.5-22kw
-
Dimension(L*W*H):
-
7000*1400*1600mm
-
Weight:
-
6000 kg
-
Product name:
-
machine light gauge steel frame
-
Raw material:
-
G550 Steel coil
-
Control system:
-
PLC(imported Brand)
-
Working material:
-
G550 Steel coil
-
Cutting blade material:
-
Cr12 Quenched
-
Color:
-
Blue white
-
Shaft material:
-
45# High Grade Steel
-
Roller material:
-
45# Steel
-
Usage:
-
Construction Building Material
-
Thickness:
-
0.7-1.2 Mm
Quick Details
-
Marketing Type:
-
Hot Product 2021
-
Work Pressure:
-
16 MPA
-
Production Capacity:
-
50m/min
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RFM
-
Voltage:
-
380V 50Hz 3phases or customer request
-
Power:
-
7.5-22kw
-
Dimension(L*W*H):
-
7000*1400*1600mm
-
Weight:
-
6000 kg
-
Product name:
-
machine light gauge steel frame
-
Raw material:
-
G550 Steel coil
-
Control system:
-
PLC(imported Brand)
-
Working material:
-
G550 Steel coil
-
Cutting blade material:
-
Cr12 Quenched
-
Color:
-
Blue white
-
Shaft material:
-
45# High Grade Steel
-
Roller material:
-
45# Steel
-
Usage:
-
Construction Building Material
-
Thickness:
-
0.7-1.2 Mm
Promotional price 55,000/set lgs frame machine
The light gauge steel frame roll forming machine is for light steel building matereial-C channel C75, C89, C140 and other profiles manufacturing. C75 could make roof structure, inner structure, C89 could make 2-3 floors steel house, C140 could make 5 floors houses.Prefabricated steel panel could be finished without any weather influence, then finish all assembling one wall by one wall, with other PC structure, heavy steel structure building methods.
Working Flow
decoiler-leveling-punching-roll forming-code printing-hydraulic cutting-profile
Machine attributes
|
After-sales Service Provided
|
Engineers available to service machinery overseas
|
|
Raw material
|
PPGI PPGL GI GL G550
|
|
Control system
|
PLC(imported Brand)
|
|
Shafter material
|
45# steel
|
|
Cutting type
|
Automatic Hydraulic Cutting
|
|
Cutting blade material
|
cr12 with quenched treatment
|
|
Color of Machine
|
Customer request
|
Machine details and introduction
Roller System
Cutting
Uncoiling system
The structure is stable, the material is strong, the appearance is beautiful, and it has the function of preventing material stripping.
While ensuring the normal operation of the machine, we have combined the problems of the original machine and added a baffle for the uncoiling part to prevent the raw material from falling off after the machine stops.
Galvanized metal frame with anticorrosive double rollers to avoid sheet scratches. It has the function of feeding guide to ensure that the position of the raw materials before entering the molding die is centered and reasonable.
In the subsequent quality inspection, we provide professional instruments to test and adjust, detect the pressure of the tubing, and the wheels. Hardness and precision. We ensure the quality of the product itself through a series of tests and bring you a better product experience.
Liming Stamping Form Machine Co.,Ltd.
occupies an area of 156,000 square meters and 6 large production plants. It has been established in 1996 with many years of production experience, serving 156 countries, 4 international machinery patents, 10 Chinese machinery patents, nationally certified high-tech company.China's top three steel-building materials equipment factories.
Products mainly include
trapezoidal steel roof/wall panel machine, C&Z shape purline machine, high-way guardrail machine, sandwich panel production line, deck forming machine, C U L light keel machine, shutter slat door forming machine, cutting machine, downpipe machine, gutter machine
, etc.
Warranty:
Two years, and we will provide technical support for wholelife of the equipment.
If some parts of machine broken within 2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
Packing Method:
Main machine is packaged with plastic film.
Transportation:
All machines need one 40 feet container to hold.
Payment Term:
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time:
Within 35 days after receiving deposit.
Q1: Can you customize the machine from your company?
A1: Of course, we can manufacture the machine according to your customized size demand.
Q2: How is the quality? Is there any department related to quality control?
A2: All raw materials we use are quality controlled.
Workers will take care of every detail when handling production and packaging. The quality control department is responsible for
the quality of each process.
Q3: Is the packaging form?
A3: Yes, of course! All our machines will be packaged in dust and water proof, and they can be reinforced after loading to fully meet export packaging standards.
Q4: How about after-sales service?
Q4: How about after-sales service?
A4: TM is online 24 hours a day, and you can also contact them via email, Skype, MSN, whatsapp.and many more Two-year warranty and parts replacement.
Q5:
How to visit your company?
A5:
1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
2)Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours) Then we can pick up you.
