Moduel
|
FSM450M-96
|
FSM460M-96
|
FSM480M-96
|
FSM490M-96
|
FSM500M-96
|
||||
|
Rated Maximum Power at STC
|
450
|
460
|
480
|
490
|
500
|
||||
|
Open Circuit Voltage(Voc/V)
|
58.57
|
58.75
|
58.89
|
58.89
|
58.95
|
||||
|
Maximum Power Voltage(Vmp/V)
|
47.87
|
48.01
|
48.35
|
48.45
|
48.63
|
||||
|
Short Circuit Current(Isc/A)
|
9.73
|
9.78
|
10.04
|
10.67
|
10.87
|
||||
|
Maximum Power Current(Imp/A)
|
9.40
|
9.59
|
9.93
|
10.12
|
10.28
|
||||
|
Module Efficiency(%)
|
17.56
|
17.95
|
18.73
|
10.12
|
19.51
|
||||
|
Power Tolerance
|
-0~+3%
|
|
|
|
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|
||||
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
