Quick Details
-
Rolling thinckness:
-
0.3-0.6mm
-
Place of Origin:
-
China
-
Brand Name:
-
XHH
-
Voltage:
-
380V/50HZ/3PH
-
Dimension(L*W*H):
-
6500*1200*1500mm
-
Weight:
-
kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Color:
-
Blue or as your request
-
Control system:
-
PLC(imported Brand)
-
Material Width:
-
1000mm
-
Material Thickness:
-
0.3mm-0.6mm
-
Effective Width:
-
875mm
-
Name:
-
roofing sheet making machine
-
Material of roller:
-
45#steel Forge
-
Height of Roofing:
-
13.7mm
Quick Details
-
Type:
-
Tile Forming Machine
-
Tile Type:
-
Steel
-
Production Capacity:
-
8-14m/min
-
Rolling thinckness:
-
0.3-0.6mm
-
Place of Origin:
-
China
-
Brand Name:
-
XHH
-
Voltage:
-
380V/50HZ/3PH
-
Dimension(L*W*H):
-
6500*1200*1500mm
-
Weight:
-
kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Color:
-
Blue or as your request
-
Control system:
-
PLC(imported Brand)
-
Material Width:
-
1000mm
-
Material Thickness:
-
0.3mm-0.6mm
-
Effective Width:
-
875mm
-
Name:
-
roofing sheet making machine
-
Material of roller:
-
45#steel Forge
-
Height of Roofing:
-
13.7mm
Focus on roll forming machine for more than
20
years
1. Factory Lifetime Service
:
offer technical support for the entire life of our machines.
2. Customized Profile :can design the profile according to customer request.
3. ONE-YEAR Guarantee Period :we could supply you the replacement parts free of charge for any damaged parts caused by quality problems.
4. Overseas Services Optional :we can send our technicians to install and train the workers in the clients' factories with extra cost.
2. Customized Profile :can design the profile according to customer request.
3. ONE-YEAR Guarantee Period :we could supply you the replacement parts free of charge for any damaged parts caused by quality problems.
4. Overseas Services Optional :we can send our technicians to install and train the workers in the clients' factories with extra cost.
Products Description
|
Model Number
|
YX13.7-875
|
|
Size
|
6500*1200*1500mm
|
|
Weight
|
5500KGS
|
|
Motor Power
|
4KW
|
|
Hydraulic Power
|
1.5KW
|
|
Voltage
|
380V/50HZ/3PH
|
|
Forming Steps
|
14 steps
|
|
Processing Speed
|
8-14m/min
|
|
Thickness
|
0.3-0.6mm
|
|
Feeding Material Width
|
1000mm
|
|
Effective Width
|
875mm
|
|
Height of Roofing
|
13.7mm
|
|
Main Accessories:
|
|
|
|
(1)
|
Main Forming Machines
|
|
|
(2)
|
5 Tons Manual Uncoiler
|
|
|
(3)
|
Hydraulic System
|
|
|
(4)
|
PLC Computer Controlling System With Touching Screen (Brand: Schneider for PLC, touching screen, cencorder and frequency changer)
|
|
|
(5)
|
Hydraulic Forming Cutter
|
|
|
(6)
|
Tools
|
|
|
(7)
|
Operation Manual
|
|
|
(8)
|
Run Out Table
|
|
Decoiler
(1) MaxWidth:1250mm
(2) Inner Diameter: 450mm
(3) out diameter:1500mm
(4) max. loading capacity:5Tons
(2) Inner Diameter: 450mm
(3) out diameter:1500mm
(4) max. loading capacity:5Tons
Roll Former
(1) Material Thickness:0.3mm-0.8mm PPGI and Gl
(2) No.of Roller Stations:14 to 18steps
(3) Materal for Rollers: high grade 45#steel polished and plated hard chrome
(4) Material for Shaft:40Cr
(2) No.of Roller Stations:14 to 18steps
(3) Materal for Rollers: high grade 45#steel polished and plated hard chrome
(4) Material for Shaft:40Cr
Cut-Off Device
(1) Material for Cut-off Modular:Crl2mov after treatment
(2) Hardness for Heat Ttreatment:HRC60-62°
(3) Cut-off Type:Hydraulic Cut-off(4)Motor for Hydraulic Stand:2.2KW
(2) Hardness for Heat Ttreatment:HRC60-62°
(3) Cut-off Type:Hydraulic Cut-off(4)Motor for Hydraulic Stand:2.2KW
PLC Control Box
(1) Type:PLC Frequency Contorol Systemwith touch screen
(2) PLC Brand:Schneider
(2) PLC Brand:Schneider
Product Application
Can not find the machine you need?
Why not customize it!
We have engineers with experience more than 17 years!
The configuration is not unique, we will provide you with customized services.
We are the roll forming machine manufacturer, and we can give you the most favorable price.
Welcome to consult price!
