Quick Details
-
Brand Name:
-
haodi machine
-
Model Number:
-
CS-A B C
-
Weight (KG):
-
999
-
Power (kW):
-
3.39
-
Voltage:
-
380V 440V
-
Wire materials:
-
gi wire
-
Type:
-
CS-A CS-B CS-C
-
outside size:
-
1976*976*1376mm
-
product capacity:
-
57-67kg/hour
-
main wire:
-
1.67-2.87mm
-
barbed wire:
-
1.67-2.52mm
-
machine power:
-
3.1kw
-
Product name:
-
Used Barbed Wire Making Machine For Sale Made In China
Quick Details
-
Wire Diameter (mm):
-
1.61 - 2.85 mm
-
Production Capacity:
-
131kg per hour
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
haodi machine
-
Model Number:
-
CS-A B C
-
Weight (KG):
-
999
-
Power (kW):
-
3.39
-
Voltage:
-
380V 440V
-
Wire materials:
-
gi wire
-
Type:
-
CS-A CS-B CS-C
-
outside size:
-
1976*976*1376mm
-
product capacity:
-
57-67kg/hour
-
main wire:
-
1.67-2.87mm
-
barbed wire:
-
1.67-2.52mm
-
machine power:
-
3.1kw
-
Product name:
-
Used Barbed Wire Making Machine For Sale Made In China
Used Barbed Wire Making Machine Manufacture In China
CS Type Hot Galvanized Used Barbed Wire Making Machine Manufacture
|
Model |
Barbed space |
Single Strand Wire Dia. |
Barbed Wire Dia. |
|
CS-A
|
3", 4", 5",6" |
1.5mm-3.0mm |
1.5mm-2.8mm |
Used Barbed Wire Making Machine Manufacture In China
Usage
This machine can produce positive and negative twisted barbed wire which is widely used in national defense, railway, highway, animal husbandry and other industries.
The materials used for positive and negative twisted barbed wire are usually hot dipped galvanized wire, electric galvanized wire etc.
Positive and negative twisted barbed wire use positive and negative way for winding flowers, the barbed wire products produced has no rebound and winding phenomenon, so it is more beautiful compared with the general barbed wire. factory razor blade razor blade Hot Galvanized Used Barbed Wire Making Machine Manufacture
Product pictures
♣ CS-A Normal twisted Hot Galvanized Used Barbed Wire Making Machine Manufacture
Parameter of the machine
raw material: hot plated low carbon steel wire, galvanized wire and pvc coated wire
torn distance: 3" 4" 5" or 4" 5" 6"
twist number: 3.5
strand diameter: 1.8-3.0mm
wire diameter: 1.7-2.8mm
theoretical yield: 80-120kg/h
motor: 3 kw
main drive shaft speed: 4 20 r/min
Production:70kg/h
weight: 1500kg
dimension of main part: 1900mm*1300mm*980mm
dimension of take-twisting part: 1800mm*750mm*750mm
easy damage parts: twist, cutter
In Carton box dimension: 204 0mm*1 6 00mm* 145 0mm
♣ CS-B Single Twist Hot Galvanized Used Barbed Wire Making Machine Manufacture
Parameter of the machine
raw material: hot plate low-carbon wire, galvanized wire
torn distance: as required
strand diameter: 1.6-2.6mm
wire diameter: 1.6-2.2mm
theoretical yield: 50-60kg/h
motor: 2.2 kw
main drive shaft speed: 357r/min
Production: 70kg/h
weight: 1200kg
dimension of main part: 1900mm*1300mm*980mm
dimension of take-twist part: 1300mm*800mm*700mm
easy damage part: twist, cutter
♣ CS-C Normal and reverse Hot Galvanized Used Barbed Wire Making Machine Manufacture
Parameter of the machine
raw material: hot plated low carbon steel wire and plastic coated wire
torn distance: 3" 4" 5" or 4" 5" 6"
twist number: 3.5
strand diameter: 1.5-2.8mm
wire diameter: 1.5-2.6mm
theroetical yield: 40kg/h
motor: 2.2 kw
main drive shaft speed: 432r/min
weight: 1200kg
dimension of main part: 1900mm*1300mm*980mm
dimension of take-twist part: 1300mm*800mm*700mm
easy damage parts: twist, cutter
Packing: Expansion film package,then put into Carton box.or only Plastic film wrapped
Our Services
1. Guarantee period: 12 months(but no longer than 18 months since departure from Port
2. Customized machine.
3. OEM support.
4. Fast delivery.
5. Moderate price.
6. Door to Door service or 24-hour email service.
---engineers available to serve machinery overseas
