Quick Details
-
Warranty:
-
12years
-
Brand Name:
-
Siqin
-
Model Number:
-
SIQIN-550(HBD)
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2279x1134x35mm
-
Dimensions:
-
2279x1134x35mm
-
Weight:
-
29g
-
Front Glass:
-
AR coating tempered glass, 2.0mm
-
Frame:
-
Anodized aluminum alloy
-
Cells:
-
TOPCon solor cell 182mm*91mm
-
Cell Orientation:
-
144 [6x24]
-
Junction Box:
-
IP68
-
Cable/Connectors:
-
4mm² / MC4 or EV02/MC4 Compatible
-
Certificate:
-
CE/DEKRA/CQC/ISO
Quick Details
-
Cell size:
-
108CELLS(6x18)
-
Type:
-
Half Cell
-
Panel Efficiency:
-
435-550w
-
Warranty:
-
12years
-
Brand Name:
-
Siqin
-
Model Number:
-
SIQIN-550(HBD)
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
2279x1134x35mm
-
Dimensions:
-
2279x1134x35mm
-
Weight:
-
29g
-
Front Glass:
-
AR coating tempered glass, 2.0mm
-
Frame:
-
Anodized aluminum alloy
-
Cells:
-
TOPCon solor cell 182mm*91mm
-
Cell Orientation:
-
144 [6x24]
-
Junction Box:
-
IP68
-
Cable/Connectors:
-
4mm² / MC4 or EV02/MC4 Compatible
-
Certificate:
-
CE/DEKRA/CQC/ISO
Product name
TOPCON N TYPE 535w 540w 545w
550w
efficiency up to 22.2% sun power watt pv module mono half cell solar panel
|
Dimensions
|
2279x1134x35mm
|
|
Weight
|
29Kg
|
|
Front Glass
|
AR coating tempered glass, 2.0mm
|
|
Frame
|
Anodized aluminum alloy
|
|
Cells
|
TOPCon solor cell 182mm*91mm
|
|
Cell Orientation
|
144 [6x24]
|
|
Junction Box
|
IP68
|
|
Cable/Connectors
|
4mm² / MC4 or EV02/MC4 Compatible
|
|
Module Type: VSIFB-480(HBD)
|
535
|
540
|
545
|
550
|
|
|
Maximum Power-Pm [W]
|
535
|
540
|
545
|
550
|
|
|
Open Circuit Voltage-Voc [V]
|
49.2
|
49.4
|
49.4
|
49.8
|
|
|
Short Circuit Current-Isc [A]
|
13.81
|
13.87
|
13.93
|
13.99
|
|
|
Maximum Power Voltage-Vm [V]
|
40
|
40.2
|
40.4
|
40.6
|
|
|
Maximum Power Current-Im [A]
|
13.05
|
13.11
|
13.17
|
13.23
|
|
|
Module Efficiency-n [%]
|
20.70
|
20.90
|
21.09
|
21.28
|
|
