Quick Details
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
SCRAMBLER
-
Displacement(cc):
-
250ML
-
Engine type:
-
LONCIN RE250
-
Engine model name:
-
166FMM
-
Bore x Stroke (mm):
-
65.5x66.2
-
Max.Power:
-
(12.5±2%)km8000rpm
-
Max.Torque:
-
(17.35±2%)nm6000rpm
-
Compression Ratio:
-
9.0:1
-
Fuel system:
-
Carburetor
-
Fuel control:
-
Carburetor
-
Ignition:
-
C.D.I
Quick Details
-
Displacement:
-
200-400CC
-
Max. Speed:
-
> 80km/h
-
Brand Name:
-
Customization
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
SCRAMBLER
-
Displacement(cc):
-
250ML
-
Engine type:
-
LONCIN RE250
-
Engine model name:
-
166FMM
-
Bore x Stroke (mm):
-
65.5x66.2
-
Max.Power:
-
(12.5±2%)km8000rpm
-
Max.Torque:
-
(17.35±2%)nm6000rpm
-
Compression Ratio:
-
9.0:1
-
Fuel system:
-
Carburetor
-
Fuel control:
-
Carburetor
-
Ignition:
-
C.D.I
Chongqing Fuego Power Co.,Ltd
E-Mail: KYLE@MOTORHEADGROUP.COM
Product Description
Specification
|
Engine and transmission
|
Displacement（cc） 223.ML
|
|
Engine type
|
LONCIN RE250 OIL COOLING 6SPEED ELECTRIC START
|
|
Engine model name
|
166FMM
|
|
Carburator Model name and Specification
|
PZ30 MANUAL CHOKE
|
|
Bore x Stroke (mm)
|
65.5x66.2
|
|
Max.Power
|
(12.5±2％）km8000rpm
|
|
Max.Torque
|
(17.35±2％）nm6000rpm
|
|
Compression Ratio
|
9.0:1
|
|
Fuel system
|
Carburetor
|
|
Fuel control
|
Carburetor
|
|
Ignition
|
C.D.I
|
|
Starter
|
Electric start
|
|
Max.Torque
|
(17.35±2%)nm6000rpm
|
|
Lubrication system
|
Pressure,splash
|
|
Cooling system
|
Air cooling
|
|
Fuel control
|
Carburetor
|
|
Transmission type
|
520H Chain Drive:13T Driven:42T
|
|
Clutch Type
|
Wet
|
|
Physical measures Dry weight
|
133
|
|
Seat height（mm）
|
825
|
|
Overall Height (mm)
|
1130
|
|
Overall Length (mm)
|
2030
|
|
Overall Width (mm)
|
840
|
|
Ground Clearance (mm)
|
250
|
|
Wheelbase (mm)
|
1355
|
|
Front suspension
|
Heavy duty hydraulic suspension, Length: 785MM
|
|
Rear suspension
|
Built in airbag、Length:305mm, Stroke length: 35mm、Max load: 870KG
|
|
Fr. Wheel Size
|
2.5-17 ; 100\90-17
|
|
Rr. Wheel Size
|
3.0-17; 130\80-17
|
|
Fr. brakes
|
Disc brake
|
|
Rr. brakes
|
Disc brake
|
|
Tire Brand
|
MANLUNG
|
|
Speed and acceleration
|
Power/weight ratio 12\133
|
|
Top speed（km/h）
|
120
|
|
Max.Loadage (kg)
|
150kg
|
|
Fuel capacity(L)
|
12L
|
|
Economical consumption of fuel
|
＜354g
|
|
Battery type
|
GEL BATTERY
|
