- Product Details
- {{item.text}}
Quick Details
-
Customized support:
-
no
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Happycare
-
Model Number:
-
HC-B078E
-
Name:
-
Stereo Microscope
-
Objective lens:
-
0.7X-4 5X
-
Display:
-
13.3 "HDMI HD
-
Optical amplification:
-
3.5X-180X
-
Black and white board:
-
95mm
-
Working distance:
-
30mm - 165mm
-
Bottom plate size:
-
200X255X22mm
-
Output interface:
-
HDMI, USB
Quick Details
-
Warranty:
-
1 years
-
Theory:
-
Stereo Microscope
-
Drawtube:
-
BINOCULAR
-
Customized support:
-
no
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Happycare
-
Model Number:
-
HC-B078E
-
Name:
-
Stereo Microscope
-
Objective lens:
-
0.7X-4 5X
-
Display:
-
13.3 "HDMI HD
-
Optical amplification:
-
3.5X-180X
-
Black and white board:
-
95mm
-
Working distance:
-
30mm - 165mm
-
Bottom plate size:
-
200X255X22mm
-
Output interface:
-
HDMI, USB
HC-B078E Laboratory Camera Microscope Stereoelectron Stereo Microscope Biological Stereo Zoom Pathology Microscope
Product Description
Display: 13.3 "HDMI HD
Optical amplification: 3.5X-180X
Eyepiece: high eye point and wide field of view self-lens WF10X20, WF20X10
Objective lens: 0.7X-4 5X
Observation head: the observation head of the three-eye stereoscopic microscope is inclined 45 °. Adjustment range of pupil distance 54mm-76mm
Black and white board: 95mm
Working distance: 30mm - 165mm
Focusing bracket: the sealing of the focusing handwheel can be adjusted and the lifting range is 50mm
Bottom plate size: 200X255X22mm
LED light source: LED quantity 144, inner diameter 64mm, diameter 94mm, input voltage AC90-240V, maximum output power 45W, voltage 12V05A
Auxiliary objective lens: 0.5X165mm, 2X30mm, 1X oil-proof lens
Camera eyepiece interface
Special interface 0.5XCTV
Output interface: HDMI, USB
Sensor: sens
Packing list:
1. Eyepiece WF10X/20-pair
2. Eyepiece WF20X/10-pair
3. Focusing frame * 1
4. Eye protection pair
5. 0.7X-4. 5X three-eye zoom objective * 1
6. 144 LED ring light * 1
7. Strut and base plate * 1
8. Dust boot * 1
9. 0.5X auxiliary lens * 1
10. 2X auxiliary lens * 1
11. 1X oil proof mirror * 1
12. 13. 3-inch display
13. 40 MP microscope camera * 1
14. HDMI HD cable * 1
15. USB data cable * 1
NF20X/10 4
16. Camera power adapter * 1
17. Optical drive * 1
18. Remote control * 1
19. Display suspender * 1
be careful:
1. Simultaneous observation through eyepiece and three-eye port, no need to switch, synchronous imaging.
2. This product is mainly HDMI output. USB connected computer can only display images and cannot adjust parameters; The remote control cannot be used when connecting the computer; Use the remote control to adjust the parameters, and connect the monitor status at HDMl.
Specification
|
item
|
value
|
|
Warranty
|
1 years
|
|
Customized support
|
no
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
Happycare
|
|
Model Number
|
HC-B078E
|
|
Theory
|
Stereo Microscope
|
|
Drawtube
|
BINOCULAR
|
|
Name
|
Stereo Microscope
|
|
Objective lens
|
0.7X-4 5X
|
|
Display
|
13.3 "HDMI HD
|
|
Optical amplification
|
3.5X-180X
|
|
Black and white board
|
95mm
|
|
Working distance
|
30mm - 165mm
|
|
Bottom plate size
|
200X255X22mm
|
|
Output interface
|
HDMI, USB
|
