Quick Details
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
China
-
Brand Name:
-
FORSUN
-
Weight (KG):
-
50 KG
-
Product Name:
-
CNC Fiber Laser Marking Machine for Carbon Steel
-
Effective cutting size:
-
110*110mm
-
Laser source:
-
Raycus IPG JPT MAX
-
Marking Speed:
-
10000mm/s
-
Marking Depth:
-
0-1.5mm
-
Working Size:
-
110*110m,200*200mm,300*300mm
-
Repeatability Accuracy:
-
±0.001mm
-
Application Materials:
-
Carbon Steel Stainless Steel Aluminum
-
Keywords:
-
Laser Marking
-
Other Name:
-
Fiber Laser Marking Machine for Steel
Quick Details
-
Working Accuracy:
-
0.001
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Laser Type:
-
Fiber Laser
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
China
-
Brand Name:
-
FORSUN
-
Weight (KG):
-
50 KG
-
Product Name:
-
CNC Fiber Laser Marking Machine for Carbon Steel
-
Effective cutting size:
-
110*110mm
-
Laser source:
-
Raycus IPG JPT MAX
-
Marking Speed:
-
10000mm/s
-
Marking Depth:
-
0-1.5mm
-
Working Size:
-
110*110m,200*200mm,300*300mm
-
Repeatability Accuracy:
-
±0.001mm
-
Application Materials:
-
Carbon Steel Stainless Steel Aluminum
-
Keywords:
-
Laser Marking
-
Other Name:
-
Fiber Laser Marking Machine for Steel
10% off!! Split Type Mini Portable Laser Engraving Machine Raycus 20w 30w 50w Fiber Laser Marking Machine-Stainless steel sample
What's the feature of our Fiber Laser Marking Machine ?
Ø Effective cutting size : 3000*1500mm*200mm
Ø Raytools Fiber Laser Cutting Head
ØCypcut control system
Ø Delta servo motor
Ø Raycus / Maxphotonics Fiber Laser
Ø Sawteeth working table
Ø Taiwan TBI Ball Screw,Germany Helical Rack and Pinion
Optional parts :
Ø4th Rotary Axis for Metal Tubes
ØEnclosed cover,protect from laser.
ØJapan Shimpo Reducer
What’s the Technical data of Forsun Fiber Laser Marking Machine ?
| Laser Source | JPT/Max/ Reci/ Raycus |
| Max Power | 20w/30w/60w/100w/120w |
| Marking Range | 110*110m,150*150mm,175*175mm,200*200mm,300*300mm working area option |
| Minimum Line Width | 0.01mm |
| Minimum Character | 0.1mm |
| Marking Speed | 10000mm/s |
| Marking Depth | 0-1.5mm |
| Engraving Line Speed | ≤7000mm/s |
| Repeatability Accuracy | ±0.001mm |
| Graphic Format Supported | BMP, JPG, GIF, TGA, PNG, TIF, AI, DXF, DST, PLT, ETC. |
| Working Environment | Clean and dust free or dust less |
| Matching system | Win7,Win8,Win9,Win10 |
| Product packing Size | 75cm* 47cm* 85cm |
| Product packing Weight | 68KG |
| Laser Module Life | >100000 hours |
What's the advantage of Forsun Fiber Laser Cutting Machine ?
|
1.Controller |
EZCAD software with stable perfomance and high reliability,Compatible with Windows XP/Vista/7/8/9/10; Supporting file types AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP; Support language English, Spanish, Arabic, Korean, Japanese |
|
2.Laser Source |
We use Chinese best brand Raycus laser generator with best cost performance.Optional:CAS/MAX/IPG/JPT color marking laser source |
|
3.Field Lens |
high system resolution and good light perception,Famous“Wavelength" brand, fast speed,high transparent rate. |
|
4.Galvo Head |
High speed galvanometer scan head ,using digital signal,high precision. |
|
5.Reducer |
Japan Shimpo Reducer -The world best reducer brand.Used for replace traditional rack and belt,to make machine more powerful and stable |
|
6.Rotary |
Which can aslo add rotary and rotary table , suitable for ring ,pens and other ring items
|
What's the benefit of Forsun CNC Fiber Laser Marking Machine?
Applicable Materials:
Most metal marking applications, such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron etc,
Many non-metal materials,such as ABS, Some non-metallic materials & Special surface treatment:silicon wafer,ceramics,plastic,rubber,epoxy resin,ABS,Nylon, PES, PVC, Makrolon.Printing ink, Plating, Spraying, Coating film.
Alloy and metal oxides: Anodized Aluminum
Applicable Industry:
They are widely applying for electronic, jewelry, automobiles, communication products, plastic buttons, IC etc.
How do we package our Forsun CNC Fiber Laser Marking Machine ?
What's our service for Forsun CNC Fiber Laser Cutting Machine ?
Guarantee:
1.5 years for the whole machine. Within 18 months under normal use and maintenance, if something is wrong with the machine, you will get spare part for free. Out of 18 months, you will get spare parts at cost price. You will also get technical support and service all the lifetime.
Technical support:
1. Technical support by phone, email, WhatsApp, Wechat or Skype around the clock
2. Friendly English version manual and operation video CD disk
3. Engineer available to service machinery overseas
After sales services:
Normal machine is properly adjusted before dispatch. You will be able to use the machine immediately after received machine.
Besides, you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by
Why Choose us???:
Customer visiting our factory
1) This is the first time I use this kind of machine, is it easy operate?
There are guide video that show how to use machine and english instruction book send to you with machine.
If there is still have any question, we will provide free professinal guide for you until you could use machine well.
2) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem.
3) MOQ ?
Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.
