Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNTS
-
Model Number:
-
CN12GF
-
Speed:
-
1500rpm
-
Weight:
-
600kg
-
Product Name:
-
Diesel Genertor
-
Type:
-
Container
-
Alternator:
-
Marathon
-
Engine:
-
Chinese Engine
-
Options:
-
Automatic Transfer Switch
-
Generator Type:
-
Household Power Silent Portable Diesel Generator
-
Color:
-
Customers' Request
-
Controller:
-
Smartgen
-
Keyword:
-
RV GENERATOR
-
Control panel:
-
LCD Digital Display
-
Certification:
-
OE
Quick Details
-
Rated Voltage:
-
220V
-
Rated Current:
-
43A
-
Frequency:
-
50HZ
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNTS
-
Model Number:
-
CN12GF
-
Speed:
-
1500rpm
-
Weight:
-
600kg
-
Product Name:
-
Diesel Genertor
-
Type:
-
Container
-
Alternator:
-
Marathon
-
Engine:
-
Chinese Engine
-
Options:
-
Automatic Transfer Switch
-
Generator Type:
-
Household Power Silent Portable Diesel Generator
-
Color:
-
Customers' Request
-
Controller:
-
Smartgen
-
Keyword:
-
RV GENERATOR
-
Control panel:
-
LCD Digital Display
-
Certification:
-
OE
|
Generators set model
|
CN220GF
|
Speed mode
|
Electronic
|
|
Prime power（KW）
|
220
|
Full load fuel consumption rate（g/kwh）
|
192.8
|
|
Standby power（KW）
|
242
|
Fuel model
|
Normal temperature
|
|
Genset capacity (KVA)
|
250
|
Coolant flow（m3/min）
|
/
|
|
Related speed (RPM)
|
1500
|
Gas volume（m3/min）
|
/
|
|
Related voltage (V)
|
400
|
Smoke exhaust（m3/min）
|
/
|
|
Rated current (A)
|
396
|
Speed mode
|
/
|
|
Related frequency(Hz)
|
50
|
cooling method
|
Closed water cooling
|
|
Rated power factor
|
0.8
|
Oil capacity(L)
|
38.6
|
|
Phase
|
3
|
Coolant capacity (L)
|
61
|
|
Reference weight（Kg）
|
2500
|
reference weight（Kg）
|
1510（Dry weight）
|
|
Reference size (L × W × H)
|
3150*1000*1780（mm）
|
Alternator model
|
HLF-220
|
|
Engine model
|
NTA855-G1A
|
Rated voltage (V)
|
400
|
|
Engine related power（KW）
|
264
|
Rated frequency(Hz)
|
50
|
|
Engine standby powe（KW）
|
291
|
Rated speed(RPM)
|
1500
|
|
Engine structural features
|
Four-stroke, turbocharged
|
Power factor
|
0.8
|
|
Cylinders / arrangement
|
6 cylinders/In-line
|
Phase and wiring
|
Three phase Y type
|
|
Bore × stroke（mm）
|
140×152
|
efficiency(%)
|
95.19
|
|
Displacement(L)
|
14
|
Excitation method
|
Brushless excitation
|
|
Compression ratio
|
14.5：1
|
Insulation class
|
H
|
|
Start method
|
Electric
|
Protection level
|
IP21
|
