Quick Details
-
Model Number:
-
S114
-
Motor Power:
-
15kw
-
Charging Capacity:
-
200kg
-
Reclaiming capacity:
-
700kg
-
Speed of Mixing Drum:
-
contact us by letter
-
Water Supply Mode:
-
contact us by letter
-
Working Cycle Period:
-
10-13min
-
Discharge Way:
-
contact us by letter
-
Outline Dimension:
-
1200*1820*2010mm
-
sand mixer:
-
$5000
Quick Details
-
Mixing Power:
-
2kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Qingzhu
-
Model Number:
-
S114
-
Motor Power:
-
15kw
-
Charging Capacity:
-
200kg
-
Reclaiming capacity:
-
700kg
-
Speed of Mixing Drum:
-
contact us by letter
-
Water Supply Mode:
-
contact us by letter
-
Working Cycle Period:
-
10-13min
-
Discharge Way:
-
contact us by letter
-
Outline Dimension:
-
1200*1820*2010mm
-
sand mixer:
-
$5000
Product Description: This series Sand Mixer with parameters of reasonable structure, advanced, mixed with shredded short cycle, high efficiency, low energy consumption, noise, long service life, sand quality and excellent features, this machine looks good, flexible operation and maintenance.
Uses: This series of sand machine widely used in large, medium and small types of mixed noodle foundry sand, core sand and single sand, can be used for building materials, chemicals, refractory ceramic and other industries in the right mix of granular materials processing.
if you want to know more products ,please visit to http://www.castingglobal.com/
Specification : The character of our this series of sand mixer : reasonable parameter, advanced structure, mixed grind cycle is short, high efficiency, low power consumption, low noise, long use-life, smooth operation, simple structure, less maintenance & reasonable cost and soon on. Especially lower plate is designed with wear-resisting cast stone material, and the abrasive resistance of this is 2 times more than that of common material.
|
Item NO. |
S1110 |
S111A |
S 114C |
S118C |
S114B |
S1124D |
|
cutter diameter ( mm ) |
Φ 1000 |
Φ 1220 |
Φ 1820 |
Φ 1800 |
Φ 1450 |
Φ 2400 |
|
Amount of Per feedstock ( kg ) |
110 |
140 |
500 |
600-700 |
300-400 |
1000-1500 |
|
productivity ( t/h ) |
1.5-2.5 |
2.8-4 |
10-13 |
13-15 |
8-10 |
23 |
|
Rotational Speed of Spindie ( r/min ) |
44 |
34.7 |
25 |
36 |
34 |
20 |
|
Power of main motor ( kw ) |
4 |
5.5 |
15 |
22 |
7.5 |
22(sixth class) |
