The differences between model 801 sending card and model
802 sending card
:
Model801 can max support 1280*1024pixels
Model802 can max support 2048*1152pixels
Single card model 802 can control 2048*640pixels
Model802 has been added the voice transmission and cascade functions
- Product Details
- {{item.text}}
Quick Details
-
Color:
-
RGB
-
Panel Size:
-
15x10mm, 15x10mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DS802(Triple-color)
-
Display Function:
-
Video
-
Operating System:
-
Windows2000,NT,XP,Vista,win7,win8
-
Support input resolution:
-
1024X768,1366X768,1280X1024,1920X1080.etc
-
Output Interface:
-
2 RJ45 interface, 3.5mm audio interface
-
Working Voltage:
-
2.5W
-
Weight:
-
0.1kg
-
Working Temperature:
-
-20℃~70℃
-
Supporting software:
-
LED Studio ( linsn )
-
Certificate:
-
CE,ROHS,FCC,ISO9001,TUV
-
Grey Scale Levels(Adjustable):
-
≤16bit
Quick Details
-
Application:
-
Display field
-
Type:
-
LED
-
Brand Name:
-
LINSN
-
Color:
-
RGB
-
Panel Size:
-
15x10mm, 15x10mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DS802(Triple-color)
-
Display Function:
-
Video
-
Operating System:
-
Windows2000,NT,XP,Vista,win7,win8
-
Support input resolution:
-
1024X768,1366X768,1280X1024,1920X1080.etc
-
Output Interface:
-
2 RJ45 interface, 3.5mm audio interface
-
Working Voltage:
-
2.5W
-
Weight:
-
0.1kg
-
Working Temperature:
-
-20℃~70℃
-
Supporting software:
-
LED Studio ( linsn )
-
Certificate:
-
CE,ROHS,FCC,ISO9001,TUV
-
Grey Scale Levels(Adjustable):
-
≤16bit
Specification
|
Setting Information
|
|
|
|
Model Number
|
||
|
Working Voltage
|
DC4.5～5.5V
|
|
|
Power Consumption
|
2.5W
|
|
|
Weight
|
0.1kg
|
|
|
Working Temperature
|
-20℃～70℃
|
|
|
Shelf life
|
1 years
|
|
|
Maximum load single card points
|
60Hz，1280×1024(Or equivalent area)、Single network port 655360 Dots
|
|
Product Description
Product Details
More features:
1. Completely Compatible with the Seventh Generation Control System
The eighth generation is developed based on the seventh. Compared with the seventh, the eighth has all the functions of the seventh. Moreover, the eighth is more functional, more powerful, more stable and more reliable.
Product Details
2. Supporting 210 colors
The seventh supports 28 colors: 28*28*28=16777216 kinds of colors.
The eighth supports 210 colors: 210*210*210=1073741824 kinds of colors. It needs to work with our video processors using the 30 bits TTL.
So the coloring number of the eighth is 64 times as much as that of the seventh.
The seventh supports 28 colors: 28*28*28=16777216 kinds of colors.
The eighth supports 210 colors: 210*210*210=1073741824 kinds of colors. It needs to work with our video processors using the 30 bits TTL.
So the coloring number of the eighth is 64 times as much as that of the seventh.
|
Model Number
|
|||||
|
Brand
|
|
|
|||
|
Operating System
|
Windows2000、NT、XP、Vista、win7、win8
|
|
|
||
|
Support input resolution
|
1024×768,1366×768,1280×1024,1920×1080.etc
|
|
|
||
|
Maximum load single card points
|
60Hz，1280×1024(Or equivalent area)、Single network port 655360 Dots
|
|
|
||
|
Output Interface
|
2 RJ45 interface, 3.5mm audio interface
|
|
|
||
|
Signal Input Interface
|
DVI
|
|
|
||
|
Grey Scale Levels(Adjustable）
|
≤16bit
|
|
|
||
|
Drive Mode
|
Static、1-32 Scan
|
|
|
||
|
Multimedia format support
|
Video：AVI、WMV、MPG、RMVB、SWF、MKV、MP4、3GP.etc Graphics： BMP、JPG、PNG、GIF.etc Audio：MP3、WAV、WMA.
|
|
|
||
|
Working Voltage
|
DC4.5～5.5V
|
|
|
||
|
Power Consumption
|
2.5W
|
|
|
||
|
Weight
|
0.1kg
|
|
|
||
|
Working Temperature
|
-20℃～70℃
|
|
|
||
|
Humidity
|
15%～85%
|
|
|
||
|
Transmission medium distance
|
HSYV-5E≤140M，HSYV-6≤170M，Optical Fiber：Unlimited
|
|
|
||
|
Language
|
Chinese、Traditional Chinese、English、French、Japanese、Russian、Thai、Spanish、Polish、Italian、Portuguese、Turkish、Dutch、Greek、Bulgarian、Romanian、Arabic、Korean、German
|
|
|
||
|
Supporting software
|
LED Studio ( linsn )
|
|
|
||
|
Certificate
|
CE,ROHS,FCC,ISO9001，TUV
|
|
|
||
Have you found out the suitable led card for your project? More advises of purchasing led sending card please contact our online service! Enjoy your shopping moment!
