Quick Details
-
Certification:
-
CE
Quick Details
-
Displacement:
-
>300cc
-
Brand Name:
-
BossATV
-
Place of Origin:
-
Zhejiang, China
-
Certification:
-
CE
|
Engine |
|
|
Engine Type |
Single cylinder, liquid-cooled, 4-stroke |
|
Engine Displacement |
275cc |
|
Bore & Stroke |
173MN |
|
Compression Ratio |
|
|
Carburetor |
Carburetor |
|
Max. Power Output |
13kW/(6500r/min) |
|
Max. Torque |
|
|
Ignition |
CDI |
|
Starter |
Electric start |
|
Drive Train |
|
|
Clutch |
Automatic |
|
Gearbox |
4-speed(high forward gear, low forward gear and one reverse gear, plus neutral gear) |
|
Final Drive |
Shaft drive |
|
Dimensions and Weight |
|
|
Length x Width x Height |
2015 x 1140 x 1195mm |
|
Wheelbase |
1205mm |
|
Front Tread |
|
|
Rear Tread |
|
|
Seat Height |
|
|
Foot Step to Seat |
|
|
Fuel Capacity |
14L |
|
Dry Weight |
295kg |
|
Max. Load |
150kg |
|
Wheels, Suspension and Brakes |
|
|
Wheels Front |
12 inch alloy rim |
|
Wheels Rear |
10 inch alloy rim |
|
Tyres Front |
AT 24X8-12 |
|
Tyres Rear |
AT 24X11-10 |
|
Suspension Front |
Independent single-wishbone |
|
Suspension Rear |
Swing arm with single shock |
|
Brakes Front |
Double hydraulic disc brakes |
|
Brakes Rear |
Double hydraulic disc brakes |
|
Packing |
|
|
Carton Size |
211x115x85.5cm |
|
G.W./N.W. |
340/295kg |
|
Container Load |
15PCS/20PCS/30PCS |
