Wifi IP Phone

Product Description

NICEUC M series IP Phone is a multi-access network, easy deployment, excellent sound quality IP Phone. It supports 1 SIP account, which features elegant appearance and easy to operate. It is an entry-level IP Phone specially designed for business office, suitable for enterprise unified communications.

Function and Feature

Why choose M series
• Modern and elegant design, exquisite workmanship, popular surface shape
• Top structure design and materials, excellent software and hardware adjusting ensure the quality of audio input and output, especially the use of strong power and full frequency horn, super-size sound chamber, makes the hands-free like big speaker, brings wonderful sound experience for personal office, which enables employees holding small hands free meeting freely
• WiFi is convenient for user's deployment, seamlessly and easily be used in the wireless office network
•Dual-core CPU, processing of voice and application independently, improve voice quality and application processing speed
• Rich application, perfectly compatible with leading IP PBX platform
• Communication security, signal encryption, media encryption, HTTPS for WEB management and uploading & downloading configuration files
• Convenient deployment and maintenance, support remote deployment by Internet
• Power adaptor protection avoid machine damage caused by error operation
• 3 meters long, durable, non-crimping handset line
• Strong package guarantee the long-distance transportation

Basis functions
• 132*52 graphic character dot matrix with backlight LCD, 1 SIP account
• Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Caller ID, Redial, Mute
• DND, Local 3-Way Conferencing, Speed Dial, Voice Mail, Local Phonebook (up to 1000 entries)
• Direct IP call without SIP proxy, Black list, White list, Dialed/Received/Missed call (each 200)
• Call Center Headsets mode

IP PBX Features
Intercom, Paging, Call pickup, Call park, Anonymous call, Anonymous call rejection, Hold on music, Conference Call, Group pickup, DND & Call forward state synchronization, Call Recording

Multiple-language
English, German, Italian, French, Spanish, Portuguese, Russian, Chinese, Arabic, Polish, Turkish,Hebrew

Advanced Features
LDAP, Microsoft active directory (AD) server, XML remote phonebook

Audio Features
• 8 own ring tone, 2 custom ring tone article, 8 volume adjustable + Mute mode, Narrowband codec: G.711(a/μ), G.729A/B/AB, G.726, iLBC,
• Wideband codec: G.722, L16, Support VAD, CNG, AEC, PLC, AJB, AGC, Full-duplex speakerphone with AEC

Network Features
• LAN / PC: support bridge mode, Open VPN support, SIP connection mode: Proxy mode, and P2P mode, Support DNS SRV (RFC3263).
• NAT transverse: STUN mode. DTMF: In-band, RFC2833, SIP INFO, Support QoS, HTTP / HTTPS web server, Package tracing export, Syslog

WiFi Features
IEEE 802.11b/g/n, Enhanced support for IEEE 802.11e QoS, Support APA, APA2, IEEE802.11i (WPA, WPA2) authentication

Security
VLAN, LLDP, IEEE802.1X, TLS, HTTPS, SRTP (RFC3711), Digest authentication using MD5/MD5-sess, AES encryption for configuration files, Phone lock, User and administrator level access control

Management
Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Remote Provision Service (RPS)

Specification

Physical
Power Interface: DC 5V-1A, 2x RJ45 10/100M or 100/1000M adaptive Ethernet ports, 1x RJ9 headphone jack, 1x RJ9 handset jack

Keys Features
1 status indicator, 3 soft keys, 5 navigation keys, 1 volume keys, 8 function keys (menu, cancel, hold, voicemail, mute, headphone, redial, hands-free)

Package
Qty/CTN: 10 PCS, G.W/CTN: 11KG, Gift box size: 280mm (L)*210mm(W)*78mm(H), Carton Meas: 425mm(L) *415mm(W) *300mm(H)

PBX Compatibility
Broadsoft, Asterisk, Elastix, Trixbox, Freeswitch, Huawei, Avaya, Mitel, Unify, ZTE, Epygi

Certifications
CE: EN60950, FCC: Part15

Details Picture

Why Choose Us

About Us

Be a Manufacturer for 18 Years-One of the first movers in VoIP products in China
We are a professional Manufacturer and national high-tech enterprise in VoIP products from 2000 year.
We can open our registeration number to every customer. Register No.:91440300723031804W, if you like, you can use this number to trace and check our company and history in Chinese goverment official system.

	Location	Size
Office	Nanshan, Shenzhen, China	456.02 Square Meters
Factory	Baoan, Shenzhen, China	2520.00 Square Meters

Strong Independent R&D Capabilities
With strong independent R&D capabilities, we can make different kinds of development works according to customer's special requirements. Both OEM and ODM services are available.

Current Situation of R&D Department:

	R&D Engineers	Experience						Average Time For New Products Launched	R&D Devices
		Over 30 Years	21-30 Years	11-20 Years	6-10 Years	2-5 Years	Less Than 2 Years
Office	9	0	5	4	0	0	0	3 months	Oscilloscope, Digital Transmission Analyzer, Vibration Tester, Eletric Parameter Test, etc.
Factory	10	1	1	1	6	1	0	3 months

So Many Big Customers
So many big customers from all over the world have been buying our products because of stable and reliable quality.

FAQ

Q: Are you trading company or manufacturer ?
A: We are factory in Telecom & VoIP products from 2000 year.

Q: How long is your delivery time?
A: Generally it takes 2 days only for one sample order; 3 days for an order with 2-5 uits; 5 days for an order with 10 units; 10 days for an order with 20 units, 20 days for an order with 50 units. Delivery time mainly depends on current stocks and production line.

Q: How long is warranty?
A: Usually warranty is one year. If you need, we can provide with 3-years warranty.

Q: How is the technical support?
A:  Free of charge by remote with 7*24 hours support for ever.

Q: How can I get a sample?
A: By placing an order or paying for a rent, then we will ship in 2 days by Express.

Q: What is your terms of payment?
A: Payment<=1000USD, 100% T/T in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.

Q: What is the best price you can offer?
A: The price is based on the order quantity. But for long cooperations, we will offer you our best price after your requirements is confirmed. We are sure you will be satisfied with it.

Q: Can you develop new functions for me?

A: Sure. Our company is a professional manufacturer and we have 18 years' history. We have strong and independent R&D capabilities.

Q: What is your MOQ?

A: Actually, our MOQ is 10 units.

Q: Do you provide OEM service?

A: Yes, OEM service in web configure page will be available for one sample (except IP Phone).
