Quick Details
-
Design Style:
-
Modern
-
Feature:
-
Metered Faucets
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Fapully
-
Model Number:
-
LY-12
-
Ceramic cartridge:
-
35mm
-
Function:
-
mixer tap
-
Accessories:
-
2pcs x50cm 304 Stainless Steel Pipes
-
Product Name:
-
panel shower walls
-
Water Pressure:
-
0.8Mpa/8Bar/8kg
-
Size:
-
1650*200
-
Quality Guarantee:
-
10 Years For Main Shower panel
-
Color:
-
Gold mirror
Quick Details
-
Material:
-
304 Stainless Steel, 304 Stainless Steel
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Bathroom
-
Design Style:
-
Modern
-
Feature:
-
Metered Faucets
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Fapully
-
Model Number:
-
LY-12
-
Ceramic cartridge:
-
35mm
-
Function:
-
mixer tap
-
Accessories:
-
2pcs x50cm 304 Stainless Steel Pipes
-
Product Name:
-
panel shower walls
-
Water Pressure:
-
0.8Mpa/8Bar/8kg
-
Size:
-
1650*200
-
Quality Guarantee:
-
10 Years For Main Shower panel
-
Color:
-
Gold mirror
Chrome Bathroom Wall Mounted Thermostatic Shower Panel Mixer Taps Triple Handle Bath Shower tap
Product Description
| Basic Information | |
| Brand | Fapully |
| Product Name | Shower Panel / Shower column |
| Model NO. | LY-12 |
| Cartridge lifetime | 500,000 times for using w/o leakage |
| Quality Control | 100% tested and inspected for Bas |
| Installation hook and screws | 304 stainless steel material |
| Hose clamp | 304 stainless steel material |
| Back water circulation pipe | Silver-grey PVC pipe with patent,6 layers constructure, 3.2mm wall thickness |
| Color | GOLD Brush |
| Main Material & Spare Parts | |
| Hot & Cold Water Mixer | H59 (CuZn40 / C28000) Standard Brass Mixer precision casting technology |
| Water Diverter | H59 (CuZn40) Standard Brass Diverter, 4 functions, precision casting |
| Mixer and Diverter Handles | Zinc Alloy with 3 layers of Ni & Cr electroplated, ≥15µm thick |
| Hand shower hose | 1.5m long stainless steel flexible shower hose with 304 stainless steel nut |
| Hand shower holder | Chromed brass material, adjustable |
| Hand shower connector | Brass hand shower connector,chromed |
| Water-inlet pipe | 2 pcs for hot & cold each, 40cm long, 304 stainless steel material |
| Back water circulation pipe | Silver-grey PVC pipe with patent,6 layers constructure, 3.2mm wall thickness |
| Installation hook and screws | 304 stainless steel material |
| Hose clamp | 304 stainless steel material |
| Technology Testing | |
| Salt spray testing | Pass 48 hours standard |
| Water Pressure Testing | 0.8Mpa/8Bar/8kg |
| Air Pressure Testing | 0.8Mpa/8Bar/8kg |
| Min Operation Pressure | 0.1Mpa/1Bar/1kg |
| Max Operation Pressure | 1Mpa/10Bar/10kg |
| Cartridge Life Time | Over 1,000,000 times to open and close |
| Quality control | 100% test |
| Water flow | Bath/Shower/Mixer >=181/min,other Mixer >=121/min |
| Intallaltion | Wall Mounted , 2 pcs of 304 stainless steel hook fixed on the wall |
| Warranty | 10 years for the main panel,3 years for the spare parts |
| Price include | Shower panel + All accessories for installation + Installation manual |
