Quick Details
-
Color:
-
1R1B1G
-
Panel Size:
-
240*120mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-FL
-
Brightness:
-
800-1200 nits
-
pixel density:
-
160000dots/sqm
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B1
-
Lifespan (hours):
-
100000hours
-
IP Rating:
-
IP31
-
Resolution:
-
160000dots/sqm
-
View Angle（H/V）:
-
140°
-
Pixels:
-
2.5mm
-
Modulator tube:
-
SMD1515
-
Best view distance/m:
-
>2.5
-
Frame rate:
-
≥60/sec
-
Drive mode:
-
Dynamic scan
-
Refresh rate/Hz:
-
1920/3840
-
1920/3840:
-
1/32
-
Maximum power w/m²:
-
700
-
Average power w/m²:
-
350
-
Controlling system:
-
Synchronous
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
1R1B1G
-
Panel Size:
-
240*120mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-FL
-
Brightness:
-
800-1200 nits
-
pixel density:
-
160000dots/sqm
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B1
-
Lifespan (hours):
-
100000hours
-
IP Rating:
-
IP31
-
Resolution:
-
160000dots/sqm
-
View Angle（H/V）:
-
140°
-
Pixels:
-
2.5mm
-
Modulator tube:
-
SMD1515
-
Best view distance/m:
-
>2.5
-
Frame rate:
-
≥60/sec
-
Drive mode:
-
Dynamic scan
-
Refresh rate/Hz:
-
1920/3840
-
1920/3840:
-
1/32
-
Maximum power w/m²:
-
700
-
Average power w/m²:
-
350
-
Controlling system:
-
Synchronous
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty periods, better after-sale services, worry-free user experience
Project Case
Transparent LED Screen
have been exported to many countries and rigions in the World, and we are highly praised by our customers.
Products Description
Specifications
|
|
P1.25
|
P1.579
|
P1.667
|
P1.875
|
P2
|
P2.5
|
P3
|
P4
|
|||||||
|
Lamp bead packaging specification
|
SMD1010
|
SMD1212
|
SMD1212
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD2020
|
SMD2020
|
|||||||
|
Pixel density (dots/m2)
|
640000
|
401111
|
360000
|
284444
|
250000
|
160000
|
111111
|
62500
|
|||||||
|
Module size (mm)
|
240x120x8.6 (L x H x T)
|
|
|
|
|
|
|
|
|||||||
|
Module Resolution
|
192x96
|
152x76
|
144x72
|
128x64
|
120x60
|
96x48
|
80x40
|
60x30
|
|||||||
|
Refresh rate (Hz)
|
3840
|
|
|
|
|
|
|
|
|||||||
|
Frame frequency (Hz)
|
60hz
|
|
|
|
|
|
|
|
|||||||
|
Gray level (bit)
|
14-18bit
|
|
|
|
|
|
|
|
|||||||
|
Signal interface mode
|
HUB75
|
|
|
|
|
|
|
|
|||||||
|
Module bottom shell material
|
Silicone soft bottom shell
|
|
|
|
|
|
|
|
|||||||
|
Module weight (kg/piece)
|
0.215
|
0.203
|
0.195
|
0.216
|
0.205
|
0.175
|
0.175
|
0.17
|
|||||||
|
Degree of protection
|
IP30
|
|
|
|
|
|
|
|
|||||||
|
Installation/maintenance mode
|
Front and rear installation/maintenance
|
|
|
|
|
|
|
|
|||||||
|
Brightness (cd)
|
≥600
|
≥650
|
≥650
|
≥750
|
≥750
|
≥750
|
≥750
|
≥750
|
|||||||
|
Color temperature (K)
|
≤12000adjustable
|
|
|
|
|
|
|
|
|||||||
|
coordinate
|
X:0.2500 Y:0.3000
|
|
|
|
|
|
|
|
|||||||
|
Brightness uniformity
|
≥95%
|
|
|
|
|
|
|
|
|||||||
|
Horizontal/vertical viewing angle
|
≥170°/≥160°
|
≥160°/≥140°
|
|
|
|
|
|
|
|||||||
|
contrast ratio
|
≥5000:1
|
|
|
|
|
|
|
|
|||||||
