Quick Details
-
Range of Spindle Speed(r.p.m):
-
50 - 2500 r.p.m
-
Max. Turned Length (mm):
-
1000 mm
-
Spindle Motor Power(kW):
-
0.9
-
Year:
-
202
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Tongchen
-
Model Number:
-
210
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
1300*390*370mm
-
Weight (KG):
-
120 KG
-
CNC or Not:
-
Normal
-
Automatic Grade:
-
Manual
-
Power (kW):
-
0.9
-
Processing Length:
-
1000mm
-
Max. Swing Diameter (mm):
-
210
Quick Details
-
Max. Length of Workpiece (mm):
-
1000
-
Machining Capacity:
-
Medium Duty
-
Spindle Bore(mm):
-
38
-
Range of Spindle Speed(r.p.m):
-
50 - 2500 r.p.m
-
Max. Turned Length (mm):
-
1000 mm
-
Spindle Motor Power(kW):
-
0.9
-
Year:
-
202
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Tongchen
-
Model Number:
-
210
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
1300*390*370mm
-
Weight (KG):
-
120 KG
-
CNC or Not:
-
Normal
-
Automatic Grade:
-
Manual
-
Power (kW):
-
0.9
-
Processing Length:
-
1000mm
-
Max. Swing Diameter (mm):
-
210
Product Description
Specification
|
Name
|
210 Common
|
210 Extension Lathe
|
210 Extension Double Chuck Lathe
|
|
voltage
|
220V 50Hz
|
220V 50Hz
|
220V 50Hz
|
|
power
|
850W
|
850W
|
850W
|
|
Spindle Through Hole
|
38mm
|
38mm
|
38mm
|
|
Spindle speed
|
50-2500 rev/min
|
50-2500 rev/min
|
50-2500 rev/min
|
|
Shift level
|
Infinitely variable speed
|
Infinitely variable speed
|
Infinitely variable speed
|
|
Machine accuracy range
|
<0.1mm
|
<0.1mm
|
<0.1mm
|
|
Tool holder swing diameter
|
100mm
|
100mm
|
100mm
|
|
Bed turning diameter
|
210mm
|
210mm
|
210mm
|
|
Two tip distance
|
400mm
|
800mm
|
1000mm
|
|
Spindle bore taper
|
Mohs 5
|
Mohs 5
|
Mohs 5
|
|
Tailstock bore taper
|
Mohs 2
|
Mohs 2
|
Mohs 2
|
|
Chuck size
|
125mm
3 chuck |
125mm
3 chuck |
125mm
3 chuck |
|
Tool holder station
|
4 stations
|
4 stations
|
4 stations
|
|
Tool holder maximum stroke
|
55mm
|
55mm
|
55mm
|
|
Middle tray travel
|
75mm
|
75mm
|
75mm
|
|
Large tray travel
|
276mm
|
276mm
|
276mm
|
|
Tailstock sleeve stroke
|
60mm
|
60mm
|
60mm
|
|
Automatic feed range
|
0.1-0.2mm
|
0.1-0.2mm
|
0.1-0.2mm
|
|
Lathe length
|
800mm
|
1200mm
|
1600mm
|
|
Lathe width
|
390mm
|
390mm
|
390mm
|
|
Lathe height
|
370mm
|
370mm
|
370mm
|
|
Lathe gross weight
|
72kg
|
85kg
|
120kg
|
