Quick Details
-
Brand Name:
-
CXZTCL
-
Model Number:
-
CX-60/120/300/800/801/802/2010
-
Operating Temperature:
-
<100℃
-
Product name:
-
Water Flow Switch
-
Application:
-
Monitor Liquid Flow
-
Liquid Pressure:
-
<0.6Mpa
-
Liquid Temperature:
-
<100℃
-
Rated voltage:
-
220VAC
-
Keywords:
-
Water Control Flow Switch
-
Body Color:
-
yellow ,black ,red ,green
-
Material:
-
Brass
-
Certification:
-
CCC
Quick Details
-
Media Type:
-
Liquid
-
Flow Rate:
-
6-7 L/min
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
CXZTCL
-
Model Number:
-
CX-60/120/300/800/801/802/2010
-
Operating Temperature:
-
<100℃
-
Product name:
-
Water Flow Switch
-
Application:
-
Monitor Liquid Flow
-
Liquid Pressure:
-
<0.6Mpa
-
Liquid Temperature:
-
<100℃
-
Rated voltage:
-
220VAC
-
Keywords:
-
Water Control Flow Switch
-
Body Color:
-
yellow ,black ,red ,green
-
Material:
-
Brass
-
Certification:
-
CCC
Products Description
1.Stable performance; induction chamber, magnetic control chamber and electronic components are designed separately in order to avoid switch failure caused by iron matter in pipeline is magnetic adsorbed.
2.High temperature resistant materials allows the product to be used for both hot water.
3.Low water pressure startup; reset spring is made of high quality stainless steel; it can start up pump when water pressure is >0.03KG.
4.The electronic components as control device will not cause spark during work which is safe.
5.This product is widely used for low pressure area family, especially important for low water pressure ignition start-up of water heater, automatic water cycle of solar water heater.
2.High temperature resistant materials allows the product to be used for both hot water.
3.Low water pressure startup; reset spring is made of high quality stainless steel; it can start up pump when water pressure is >0.03KG.
4.The electronic components as control device will not cause spark during work which is safe.
5.This product is widely used for low pressure area family, especially important for low water pressure ignition start-up of water heater, automatic water cycle of solar water heater.
|
Model
|
Size
|
Max current
|
Work current
|
Power
|
|
CXZ-2010
|
G 2"-2"
|
5A
|
2A
|
2200w
|
|
CXZ-802
|
G 1.5"-1.5"
|
5A
|
2A
|
2200w
|
|
CXZ-801
|
G1.2"-1.2"
|
4A
|
1.6A
|
2200w
|
|
CXZ-800
|
G1"-1"
|
4A
|
1.6A
|
800w
|
|
CXZ-300/370
|
G1"-3/4"
|
5A
|
2A
|
300-370w
|
|
CXZ-300
|
G 3/4 "-3/4"
|
5A
|
2A
|
300w
|
|
CXZ-300
|
G 3/4 "-1/2"
|
5A
|
2A
|
300w
|
|
CXZ-300
|
G 1/2 "-1/2"
|
5A
|
2A
|
300w
|
|
CXZ-200
|
G1"-3/4"
|
4A
|
1.6A
|
200w
|
|
CXZ-200
|
G 3/4 "-3/4"
|
4A
|
1.6A
|
200w
|
|
CXZ-200
|
G 3/4 "-1/2"
|
4A
|
1.6A
|
200w
|
|
CXZ-200
|
G 1/2 "-1/2"
|
4A
|
1.6A
|
200w
|
|
CXZ-120
|
G1"-3/4"
|
1.5A
|
0.5A
|
120w
|
|
CXZ-120
|
G 3/4 "-3/4"
|
1.5A
|
0.5A
|
120w
|
|
CXZ-120
|
G 3/4 "-1/2"
|
1.5A
|
0.5A
|
120w
|
|
CXZ-120
|
G 1/2 "-1/2"
|
1.5A
|
0.5A
|
120w
|
|
CXZ-60
|
G1"-3/4"
|
1A
|
0.3A
|
90w
|
|
CXZ-60
|
G 3/4 "-3/4"
|
1A
|
0.3A
|
90w
|
|
CXZ-60
|
G 3/4 "-1/2"
|
1A
|
0.3A
|
90w
|
|
CXZ-60
|
G 1/2 "-1/2"
|
1A
|
0.3A
|
90w
|
