Quick Details
-
Brand Name:
-
Huahang
-
Dimension(L*W*H):
-
660 mm Height X 324mm OD
-
Weight:
-
2.2 KG
-
filter media:
-
Polyester fibers,micronfiber
-
filration rating:
-
3-100 micron
-
type:
-
pleated air filter cartridge
-
Advantages:
-
Larger filter area,good Air Permeability
-
Usage:
-
Machines & industrial profiles
-
Measurements:
-
660 mm Height X 324mm OD
-
Trade terms:
-
EXW,FOB,CFR
-
Payment:
-
Pay the full amount in advance by T/T/50% pre-payment
-
condition:
-
new
-
Function:
-
Air Filtraion
Quick Details
-
Core Components:
-
air filter cartridge
-
Efficiency:
-
99.9%
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Huahang
-
Dimension(L*W*H):
-
660 mm Height X 324mm OD
-
Weight:
-
2.2 KG
-
filter media:
-
Polyester fibers,micronfiber
-
filration rating:
-
3-100 micron
-
type:
-
pleated air filter cartridge
-
Advantages:
-
Larger filter area,good Air Permeability
-
Usage:
-
Machines & industrial profiles
-
Measurements:
-
660 mm Height X 324mm OD
-
Trade terms:
-
EXW,FOB,CFR
-
Payment:
-
Pay the full amount in advance by T/T/50% pre-payment
-
condition:
-
new
-
Function:
-
Air Filtraion
Product Description
Air filter cartridge--------Introduction
|
Features and Advantages
|
1) Imported long fiber polyester filter media,fiber interwoven,evenly distributed.
2) Filter material surface do waterproof and oil processing. 3) Good abrasion resistance,and the capability of withstand airflow pulse inverse blow is better than traditional filter media. 4) Smooth filter media surface,not sticky. 5) Excellent chemical resistance. 6) Electro-galvanized / stainless steel cover, central skeleton. 7) Professional sealing obturator elastic neoprene. 8) Good filter material stiffness,can be repeated washed. 9) Operating temperature ≤ 135 ° C. 10) Greatly increase the effective filtration area. 11) Ensure a low steady differential pressure, improve the circulation of air flow. 12) Small filter cartridge element, easy to install. 13) Especially suitable for large dust concentration industry. |
|
Specifications
|
1. Type: Pleated cartridge filter
2. Size: 660mmheight X324diameter 3. Filter media: Microfiber 4. Efficiency: 99.99% 5. Inside frame and outer frame:metal mesh 6. We can make different sizes and precision as your need. |
More dimensions for your choice
|
Cartridge Model
|
Out diameter
|
Internal diameter
|
Height measurements
|
|
HX/F3266
|
Φ324mm
|
Φ213mm
|
660mm
|
|
HX/F3566
|
Φ352mm
|
Φ241mm
|
660mm
|
|
HX/F3275
|
Φ324mm
|
Φ213mm
|
750mm
|
|
HX/F3288
|
Φ324mm
|
Φ213mm
|
880mm
|
|
HX/F3290
|
Φ324mm
|
Φ213mm
|
915mm
|
Some specifications
Applicable to spray painting, sand blasting operations, paint industry, wood processing filter.
1. Imports of long fiber polyester filter material, fiber interlock, widely distributed
2. Abrasion resistance, better able to weather than traditional air pulse filter cleaning
3. Filter material stiffness is good, and can be repeatedly cleaned
4.End caps, the central skeleton parts are galvanized, not rust
5. Special sealed closed-cell flexible neoprene
6. The use of temperature 93°C-135°C
1. Imports of long fiber polyester filter material, fiber interlock, widely distributed
2. Abrasion resistance, better able to weather than traditional air pulse filter cleaning
3. Filter material stiffness is good, and can be repeatedly cleaned
4.End caps, the central skeleton parts are galvanized, not rust
5. Special sealed closed-cell flexible neoprene
6. The use of temperature 93°C-135°C
