Quick Details
-
Model Number:
-
EPM-EPK-1
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Application:
-
Industrial Control
-
Product name:
-
Safety Interlock Switch Safety Door Switch
-
Model:
-
EPM-EPK-1
-
Humidity:
-
85%
-
Certification:
-
TUV
-
Durability:
-
mechanical 1000000min/electrical 300000min
-
voltage type:
-
AC-15
-
rated operating voltage:
-
400v
-
Material:
-
resin/metal
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ESPE
-
Model Number:
-
EPM-EPK-1
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Application:
-
Industrial Control
-
Product name:
-
Safety Interlock Switch Safety Door Switch
-
Model:
-
EPM-EPK-1
-
Humidity:
-
85%
-
Certification:
-
TUV
-
Durability:
-
mechanical 1000000min/electrical 300000min
-
voltage type:
-
AC-15
-
rated operating voltage:
-
400v
-
Material:
-
resin/metal
Welcome to ESPE!
Safety Components on Safety Gates and Doors 1NC 1NO 2NC Safety Door Switches Safety Interlock Switches
Here we just show an example, please contact us for more models. You're special for us and deserve our special customization service.
- Cost-effective and high quality
- Quick delivery time
- Support ODM & OEM service
- Professional technical service support
- 20 years experience and Chinese benchmark factory
Product range: Safety light curtain, safety door switch, safety relay, measuring light curtain, vehicle separator, laser lidar, photoelectric sensor
| Model | EPM-C0F |
| Standard | IEC60947-5-1/ EN60947-5-1/ GB14048.5-2017 |
| Protection degree | IP65 (EN60947-5-1, except key hole) |
| Durability |
Mechnical 1,000,000 min
Electrical 300,000 min |
| Rated insulation voltage (Ui) | 300v |
| Rated impulse withstand voltage (Uimp) | 4kV |
| Nomical discharge current (Ith) | 8A |
| Voltage type | AC-15 |
| Rated operating voltage (Ue) | AC400V |
| Rated operating current (Ie) | 2A |
| Rated conditional short-circuit current | 1000A |
| Direct opening force | 60N min |
| Direct opening travel | 10mm Min |
| Operating speed | 0.01-0.5/s |
| Operating frequency | Maximum 20 times/minutes |
| Operating temperature | -20-60°C (with no freezing) |
| Operating humidity | 85%RH |
Safety Components on Gates and Doors 1NC 1NO 2NC Safety Door Switches Safety Interlock Switches
