Quick Details
-
Input Voltage:
-
240VAC±15%
-
Display:
-
LED indicator
-
Color:
-
White ( customized )
-
Cable length:
-
5M ( customizable )
-
Charging Type:
-
Type1/ Type2 / GB/T
-
Application:
-
Home Use
-
Certificate:
-
CE TUV
-
Installation method:
-
Wall-monuted
-
Communication:
-
WIFI / APP / Bluetooth
-
IP Grade:
-
IP 55
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
HR07
-
Brand Name:
-
HOSTON
-
Input Voltage:
-
240VAC±15%
-
Display:
-
LED indicator
-
Color:
-
White ( customized )
-
Cable length:
-
5M ( customizable )
-
Charging Type:
-
Type1/ Type2 / GB/T
-
Application:
-
Home Use
-
Certificate:
-
CE TUV
-
Installation method:
-
Wall-monuted
-
Communication:
-
WIFI / APP / Bluetooth
-
IP Grade:
-
IP 55
|
Specification |
HR07 ( Type-C ) Cable Outlet |
HR07 ( Type-A/B ) Socket Outlet |
|
|
Electrical |
Rated Power |
7kW |
|
|
Output Current |
32A |
||
|
Input Voltage |
AC240V±15% |
||
|
Input Frequency |
50Hz/60Hz |
||
|
Rated Output Voltage |
300-1000V |
||
|
Constant Power Interval Voltage |
300-1000V |
||
|
Voltage Accuracy |
≤±0.5% |
||
|
Current Accuracy |
≤±1% |
||
|
Harmonic Coefficient |
≤±0.5% |
||
|
Maximum Module Efficiency |
≥95% |
||
|
Power Factor |
> 0.99 |
||
|
Environment |
Temperature |
-30 ℃ ~+ 55 ℃ |
|
|
Humidity |
5%~95% ( No condensation ) |
||
|
Altitude |
≤2000m ( Derating above 2000m ) |
||
|
Protection Grade |
IP55 |
||
|
Cooling Method |
Air Cooling |
||
|
Noise Control |
< 50 db |
||
|
Structure |
Equipment Size(L*W*H) |
244mm×164mm×126mm |
|
|
Weight |
4kg |
2.2kg |
|
|
Materials |
Plastics |
||
|
Installation |
Wall mounted / Column mounted |
||
|
Cable Length |
5m |
/ |
|
|
Function |
Communication Interface |
Wifi, Bluetooth, LORA, 4G |
|
|
LED |
√ |
||
|
Emergency Stop Button |
√ |
||
|
Remote upgrade |
√ |
||
|
Safety Specifications |
Protection Function |
Overvoltage protection, undervoltage protection, overload protection, short circuit protection, leakage protection, grounding protection, high temperature protection, low temperature protection, lightning protection |
|
|
Standards |
IEC-61851-1, IEC61851-21-1, IEC61851-21-2, IEC61851-22, IEC-61851-23, DIN SPEC 70121-2014, ISO 15118-3 |
||
