Quick Details
-
Brand Name:
-
OMR
-
Model Number:
-
D2F D2F-L D2F-F D2F-FL D2F-01L D2F-L2 D2F-L3
-
Max. Current:
-
3A
-
Operating Temperature:
-
-40~85
-
Protection Level:
-
IP
-
MOQ:
-
50PCS
-
Product name:
-
Photoelectric sensor
-
Warranty:
-
1year
-
Condition:
-
100% Original
-
Delivery time:
-
1-3 Days
-
Certification:
-
ROHS
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
125VAC
-
Place of Origin:
-
Japan
-
Brand Name:
-
OMR
-
Model Number:
-
D2F D2F-L D2F-F D2F-FL D2F-01L D2F-L2 D2F-L3
-
Max. Current:
-
3A
-
Operating Temperature:
-
-40~85
-
Protection Level:
-
IP
-
MOQ:
-
50PCS
-
Product name:
-
Photoelectric sensor
-
Warranty:
-
1year
-
Condition:
-
100% Original
-
Delivery time:
-
1-3 Days
-
Certification:
-
ROHS
Product Description
| Parts no. | D2F |
| Part Status | Active |
| HTS | 8536.50.90.40 |
| Switch Configuration | N.O./N.C. |
| Actuator Style | Hinge Lever |
| Pole Throw Configuration | SPDT |
| Maximum Current Rating (A) | 3@125VAC |
| Electrical Life (Cycles) | 30000 |
| Mechanical Life (Cycles) | 1000000 |
| Maximum Movement Differential (mm) | 0.5 |
| Mounting | Through Hole |
| Termination Style | PC Pins |
| Body Orientation | Straight |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Body Length (mm) | 12.8 |
| Body Depth (mm) | 5.8 |
| Body Height (mm) | 6.5 |
| Operating Force (N) | 0.78 |
