Quick Details
-
Model Number:
-
Support customization
-
Material:
-
Synthetic Rubber
-
Product name:
-
High Pressure Hose
-
Application:
-
Extensive
-
Quality:
-
High Quaility
-
MOQ:
-
1meter
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
jiaer
-
Model Number:
-
Support customization
-
Material:
-
Synthetic Rubber
-
Product name:
-
High Pressure Hose
-
Application:
-
Extensive
-
Quality:
-
High Quaility
-
MOQ:
-
1meter
Product Description
High pressure hose is mainly used for mine hydraulic support, oil field development, it is suitable for transporting petroleum base (such as mineral oil, soluble oil, hydraulic oil, fuel oil, lubricating oil) and water-based liquid (such as emulsion, oil-water emulsion, water) with certain pressure (higher pressure) and temperature and liquid transmission in engineering construction, lifting and transportation, metallurgical forging, mining equipment, ships, injection molding machinery, agricultural machinery, various machine tools and mechanized and automatic hydraulic systems of various industrial departments, resistant to working pressure up to 70-120Mpa.
High pressure hose is the 1 kind of pipeline used to transport high pressure fluid, which is commonly used in industry, agriculture and construction. The high-pressure hose has the advantages of compression resistance, wear resistance, corrosion resistance, high temperature resistance and low temperature resistance, and also has the characteristics of easy bending, easy connection and easy installation.
The high-pressure hose adopts a special material treatment process, which makes it fully equipped with the characteristics of weather resistance, corrosion resistance, flame retardancy, etc., even in extremely harsh environments, the high-pressure hose can continue to perform well. At the same time, the inner wall of the high-pressure hose is smooth and flat, which also helps prevent dirt accumulation and corrosion.
Product features:
1.
The hose is made of special synthetic rubber, which has excellent oil resistance, heat resistance and aging resistance.
2
.
The hose has high pressure and superior pulse performance.
3.
The tube body is tightly combined, soft to use, and has little deformation under pressure.
4.
The hose has excellent bending resistance and fatigue resistance.
|
ID (mm)
|
ID (inch)
|
Wall (mm)
|
WP (bar)
|
BP (bar)
|
Radius (mm)
|
Weight (kg/m)
|
|
|
6
|
1/4
|
3,5
|
16 / 20
|
50 / 60
|
35
|
0.17
|
|
|
8
|
5/16
|
3,5
|
16 / 20
|
50 / 60
|
50
|
0.25
|
|
|
10
|
3/8
|
3,5
|
16 / 20
|
50 / 60
|
60
|
0.29
|
|
|
13
|
1/2
|
4,0
|
16
|
48
|
60
|
0.37
|
|
|
13
|
1/2
|
5,0
|
20
|
60
|
70
|
0.42
|
|
|
16
|
5/8
|
4,0
|
16
|
48
|
80
|
0.45
|
|
|
16
|
5/8
|
4,5
|
20
|
60
|
90
|
0.48
|
|
|
19
|
3/4
|
5,0
|
16
|
48
|
110
|
0.58
|
|
|
19
|
3/4
|
5,5
|
20
|
60
|
125
|
0.60
|
|
|
25
|
1
|
5,0
|
20
|
48
|
130
|
0.72
|
|
|
25
|
1
|
5,5
|
16
|
60
|
150
|
0.83
|
|
|
32
|
1-1/4
|
6,0
|
10
|
30
|
230
|
0.94
|
|
|
38
|
1/1-2
|
6,0
|
10
|
30
|
270
|
1.08
|
|
|
50
|
2
|
7,0
|
10
|
30
|
400
|
1.80
|
|
