Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
KADOYAEVERBRIGHT
-
Dimension(L*W*H):
-
1130*1130*1540mm
-
Weight:
-
230, 230kg
-
Product style:
-
Stainless steel storage tank
-
Lifetime:
-
10-15years
-
MOQ:
-
1
-
Material:
-
SUS304/316L
-
Surface treatment:
-
Acid-washing
-
Medium:
-
Liquid
-
Outer Frame:
-
Stainless steel(Optional Hot-dip iron)
-
Shape:
-
Round
-
Application:
-
Chemcial Storage
Quick Details
-
Capacity:
-
1000L
-
Max Working Pressure(MPa):
-
0.02 MPa
-
Core Components:
-
Valve
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
KADOYAEVERBRIGHT
-
Dimension(L*W*H):
-
1130*1130*1540mm
-
Weight:
-
230, 230kg
-
Product style:
-
Stainless steel storage tank
-
Lifetime:
-
10-15years
-
MOQ:
-
1
-
Material:
-
SUS304/316L
-
Surface treatment:
-
Acid-washing
-
Medium:
-
Liquid
-
Outer Frame:
-
Stainless steel(Optional Hot-dip iron)
-
Shape:
-
Round
-
Application:
-
Chemcial Storage
Specification
|
Capacity
|
1000L
|
|
Medium
|
Liquid
|
|
Material
|
Stainless steel 304(Optional 316/316L)
|
|
Dimension
|
1152*1152*1140mm
|
|
Inlet
|
Sanitary grade 2-inch inlet nozzle
|
|
Outlet
|
Sanitary grade 2-inch butterfly ball balve
|
|
Material of gasket
|
PTFE
|
|
Working pressure
|
Normal pressure
|
|
Thickness
|
2.5mm
|
|
Usage
|
Store and transport normal liquid or sticky liquid. For example oil, tomato sauce, coconut oil and so on
|
|
Note
|
Above specification is only for this product, we also accept OEM and ODM. In addition, our engineers can design it and make
drawing according to each customer's requirements before producing products. So if you want to learn more other products, please look through our website:www.etech-eng.com or please feel free to contact me. |
Eccentric bottom and it can make the materials
discharge thoroughly without residue.
Short discharge pipe is connected with a butterfly ball valve,
which is easy to disassemble and clean each corner of tank
thoroughly.
This breathing valve is used for balancing the
pressure inner and outer tank, When we use it,
it can keep safety
Quick connector can save time and it has a chain to connect
with this nozzle, prevent the cover from being lost when the cover is opened
